Highlights
- The camera window:
- Small raindrops creative design, process quality
- OV9712+ haisi 3518e 720p HD chip
- 1.3MP high-definition camera, large screen display is clear
- hidden infrared ceramic lamp, night clear imaging
- 64 wireless access and alarm function
- Creativity chassis, folding bracket design, easy to deploy installation, manual level 0~360 degrees, 90 degrees vertical adjustment.
- Multistory precision heavy gold PCB process, moisture-proof to oxidation
- The camera APP:
- Add camera. Mobile WiFi, super experience
- Mobile wireless alarm equipment list, custom wireless alarm name, power display
- Mobile video storage and playback, video operation more simple
- Abnormal TF card phones according to the video cameras will alarm prompt, alarm function more powerful
- The function of image zoom in on your mobile phone, excellent experience
- Mobile phone online upgrade camera APP and new software
- Comprehensive window:
- Intelligent wireless WiFi, access convenient and simple
- The drawer - CUT full metal IR dual filter, high reliable, stable life
- Two-way voice, eliminate noise suppression circuit, high power the horn
- Easy to install, easy to access, easy to use, easy to maintain
- Real-time alarm a mobile phone and rang the bell, APP cloth machine Settings, the operation is simple
- Mobile video capture the preservation and look at it
- Mobile phone to check the alarm record, voice call the police
- The mobile detection, voice alarm sensitivity adjustment function
- Mobile video screenshots store photos to mobile phone photo album by default
- The function of APP and PC software easy to download and install, rich, mature and stable
Specification
|
Model |
CN-C200D |
|
|
Video Compression |
Operation System |
H.264 Baseline profile |
|
Video |
Image Sensor |
1.0MP HD CMOS Sensor |
|
|
Core Chipset |
HI3518E Chipset |
|
|
Resolution |
720P HD images, resolution up to 1280X720,1.0MP |
|
|
Resolution Variable |
720P(1280*720),VGA(640*480), QVGA(320*240)SS |
|
|
Frame Rate |
1~30fps |
|
|
Min. Illumination |
Color: 1.5 Lux; W/B: 0 Lux with IR LED ON |
|
|
IR Distance |
Dual IR cut filter with auto switch,1pcs high-power IR LED, night vision 15 meter |
|
|
S/N Ratio |
≥38dB |
|
|
CMOS Features |
Support AWB,AGC,BLC |
|
|
Lens/Visual Angel |
|
|
System Feature |
Security |
Account, password user authentication |
|
|
Adaptive dynamic IP domain name system(Free) |
No need domain name, support dynamic IP, no application of “peanut shells”, completely solve the problem of frequently dropped calls, connection with high speed |
|
|
Mobile phone monitor |
Support megapixel HD mobile phone monitor, dedicated IPHONE software, Android software(Software version required IOS4.3,Android 2.3 and above) |
|
|
On-board storage |
Support external 32GB Micro SD card,24 hours recording |
|
|
Plug and Play |
Adopting advanced Cloudlink P2P (Plug and play) technology, network penetration up to 99%, applicable to all kinds of complex networks, installation takes only three steps: 1. Connecting power supply and network, 2. Installing mobile phone software; 3. Viewing CCTV images. |
|
|
Server Clusters |
P2P intelligent clusters of servers throughout the world, protect the pan-tilt home IP camera works stable and efficient |
|
Audio |
Audio Compression: |
G.711A |
|
|
Audio Input |
1CH built-in 38dB microphone |
|
|
Audio Output |
Built-in speaker(8Ω2W) |
|
Video Management |
Recording Mode |
Manual recording, timing recording and alarm recording |
|
|
Video Storage |
TF Card |
|
Network |
Ethernet |
10Base -T, /100Base-TX, RJ45 Connector |
|
|
Protocols |
TCP/IP,HTTP,TCP,UDP,SMTP, DHCP,DNS,DDNS,NTP,UPnP,P2P etc |
|
|
Wireless |
WiFi 802.11b/g/n wireless network |
|
Alarm |
Alarm Input |
Learning wireless sensor alarm input |
|
|
Motion Detection |
Support |
|
|
Alarm Detection |
Max. 64ch wireless alarm sensor, support one key defense setting and delete |
|
|
Alarm Action 1 |
Speaker alarm and call 5 different mobile phones |
|
|
Alarm Action 2 |
Capture photos and send by E-mail |
|
System Requirement |
System Configuration |
Software version IOS4.3,Android 2.3 and above |
|
General |
Material |
Cartoon robot/engineering plastics |
|
|
Working Environment |
Indoor |
|
|
Power Supply |
DC5V 2A |
|
|
Working Temperature |
-10~50 ºC |
|
|
Working Humidity |
95% RH |
|
|
Accessories Optional |
Wireless door contact and Controller |
|
|
Installation Method
|
Mounted on bracket or Flat type |
What's in the box?
- 1 x Camera
- 1 x Base Stand
- 1 x USB cable
- 1 x Power adapter
- 3 x Screws
- 1 x User manual
