Highlights
Advanced TV Application - Watch DVB-T2&DVB-T TV on Android Phone/Pad with USB OTG
Rewind and Fast Forward live TV shows with Time shifting recording
Electronic Program Guide (EPG) and Supporting HDTV Receiving
Automatic TV channels searching
Create favorite channels for convenient watching
High sensitivity under low signal broad casting area
A Brief Introduction of DVB Standards:
DVB = Digital Video Broadcast
DVB - T = T for Terrestrial, that means you pick up the signals with a terrestrial aerial.
DVB -S = S for Satellite, you pick up the signal from a satellite dish.
DVB - C = C for Cable, a card like this can get signals from a cable fed system.
Specification
| General | |
|---|---|
| Model | D202 |
| Quantity | 1 Piece |
| Specification | |
|
Input Signal |
75 Ohm Digital TV Antenna Input |
| Receive Frequency | 48.25 ~ 863.25 MHz |
| Compliance | Fully Compliant with DVB-T2: EN302 755; DVB-T: EN300 744 |
| FFT | 2K to 8K FFT Size |
| Punctured Codes | 1/2, 2/3, 3/4, 4/5, 5/6 & 7/8 |
| Bandwidth | 1.7/5/6/7/8/10MHz |
| De-Multiplexing |
Max No. Section filtering: 32PIDS Engine: Software Stream capture: PES & TS |
| Recording Format |
Video Format: MPEG2 MP & ML / H.264 Audio Format: MPEG2 Audio Layer I & II / AAC |
| System Requirements |
Android 4.2 or above Android device have OTG functionality |
| Operation |
First ,download and install the the apk of Pad TV HD in your Android device For the first time usage or if you want to update your TV channels ,go to “setting” and click on the “Channel Scan.” |
| Dimensions & Weight (Main Product) | |
| Dimension | 32*25*9mm/1.25*0.98*0.35inches |
| Package Contents | |
|
1*Pad TV tuner |
|
| 1*Antenna | |
| 1*Quick installation guide | |
