Highlights
Camera with 1-inch 20MP Sensor
An upgraded camera is equipped with a 1-inch 20-megapixel sensor capable of shooting 4K/60fps video and Burst Mode stills at 14 fps. Advanced sensors and processors ensure everything is captured with more image detail and the image data needed for advanced post-production
Five-directions of Obstacle Sensing
The FlightAutonomy system adds dual rear vision sensors and infrared sensing systems for a total of five-directions of obstacle sensing and four-directions of obstacle avoidance, front and rear sensing range of up to 98ft(30m), protecting the Phantom 4 Pro from more obstacles and giving filmmakers the confidence to capture more complex images.
Multiple Flight Modes
Phantom 4 Pro offers three modes for flight: P, A and S. Switching between them allows pilots to get the control they need, whether they seek smoothness, simplicity, intelligent navigation or speed.
In Position Mode, TapFly, ActiveTrack, obstacle sensing and positioning features are available. Sport Mode adds extra agility and higher speed, reaching 45mph (72kph).
7KM Long-range Control
Using brand new DJI Lightbridge HD video transmission technology, the Phantom 4 Pro has a maximum transmission range of 4.3i(7km). Before each flight, it scans a range of available frequencies to find and use the one with the least interference. By supporting 2.4GHz and 5.8 GHz frequency bands, it gives you more reliable control.
Longer Flight Time
The Phantom 4 pro has a maximum flight time of 30 minutes frome a 5870mAh removable battery, providing more time in the air to capture the perfect shot.
DJI GO APP
Using the DJI GO app, a large number of Intelligent Fight Modes are available. It also provides access to full manual camera controls, including ISO, aperture, shutter speed, image formats, and more. Any changes in DJI GO will appear almost instantly on-screen.
Specification
|
General
|
Brand: DJI
Model: Phantom 4 Pro
Quantity:1 Piece
|
|
Quadcopter
|
Max Ascent Speed S-mode: 6 m/s;P-mode: 5 m/s
Max Descent Speed S-mode: 4 m/s;P-mode: 3 m/s
Max Speed : 45 mph (72 kph) (S-mode);36 mph (58 kph) (A-mode);31 mph (50 kph) (P-mode)
Max Tilt Angle: 42°(S-mode); 35°(A-mode);25°(P-mode)
Max Angular Speed: 250°/s (S-mode);150°/s (A-mode)
Max Service Ceiling Above Sea Level: 19685 ft (6000 m)
Max Flight Time: Approx. 30 minutes
Operating Temperature: 32°to 104°F ( 0°to 40° C)
Satellite Positioning Systems: GPS/GLONASS
GPS Hover Accuracy Range: Vertical: ±0.1 m (With Vision Positioning),±0.5 m (With GPS Positioning);Horizontal: ±0.3 m (With Vision Positioning),±1.5 m (With GPS Positioning)
|
|
Transmitter
|
Operating Frequency: 2.400 - 2.483 GHz and 5.725 - 5.850 GHz
Max Transmission Distance: FCC Compliant: 4.3mi (7km);CE Compliant: 2.2mi (3.5km) (Unobstructed, free of interference)
Operating Temperature: 32° to 104° F (0° to 40° C)
Battery: 6000mAh LiPo 2S
Transmitter Power (EIRP): 2.400 GHz - 2.483 GHz FCC: 23 dBm; CE: 17 dBm;5.725 GHz - 5.850 GHz FCC: 30 dBm; CE: 14 dBm
Operating Voltage: 1.2 A @7.4 V
Video Output Port: GL300E: USB
GL300F: HDMI,USB
Mobile Device Holder: GL300E: Tablets and smart phones;GL300F: Built-in display device (5.5 inch screen, 1920×1080,1000 cd/m2, Android system, 4G RAM+16G ROM)
|
|
Intelligent Flight Battery (PH4-5870MAH-15.2V)
|
Capacity: 5870 mAh
Voltage: 15.2 V
Battery Type: LiPo 4S
Energy: 89.2 Wh
Net Weight: 468 g
Charging Temperature Range: 14 to 104° F (-10 to 40° C)
Max Charging Power: 100 W
|
|
Charger
|
Voltage: 17.4 V
Rated Power: 100 W
TOF Sensing System:
Obstacle Sensory Range: 0.6 –23 ft (0.2–7 m)
FOV: ±35° (Horizontal);±10° (Vertical)
Detection Frequency: 10 Hz
Operating Environment: Surface with diffuse reflection material,and reflectivity > 8% (such as wall, trees, humans, etc.)
|
|
Vision System
|
Velocity Range: ≤31 mph (50 kph) at 6.6 ft (2 m) above ground
Altitude Range: 0–33 ft (0–10 m)
Operating Range: 0–33 ft (0 –10 m)
Obstacle Sensory Range: 2–98 ft (0.7–30 m)
FOV: ±60°(Horizontal);±54°(Vertical)
Detection Frequency: 10Hz
Operating Environment: Surfaces with clear patterns and adequate lighting (> 15 lux)
|
|
Gimbal
|
Stabilization: 3-axis (pitch, roll, yaw)
Controllable Range: Pitch: -90°to +30°
Max Controllable Angular Speed: Pitch: 90°/s
Angular Control Accuracy: ±0.03°
|
|
Camera
|
Sensor: 1" CMOS; Effective pixels: 20M
Lens: FOV (Field of View) 84°, 8.8 mm / 24 mm (35 mm format equivalent),f/2.8 - f/11 ; auto focus at 1 m - ∞
ISO Range: Video: 100 - 3200 (Auto) 100 - 6400 (Manual); Photo: 100 - 3200 (Auto) 100- 12800 (Manual)
Mechanical Shutter: 8 - 1/2000 s
Electronic Shutter: 8 - 1/8000 s
Max Image Size: 3:2 Aspect Ratio: 5472 x 3648;4:3 Aspect Ratio: 4864 x 3648;16:9 Aspect Ratio: 5472 x 3078
PIV Image Size: 16:9 Aspect Ratio: 5248 x 2952(3840 x 2160 24/25/30p,2720 x 1530 24/25/30p,1920 x 1080 24/25/30p, 1280 x 720 24/25/30p); 3840 x 2160(3840 x 2160 48/50p,2720 x 1530 48/50p,1920 x 1080 48/50/60p,1280 x 720 48/50/60p) . 17:9 Aspect Ratio: 4896 x 2592 (4096 x 2160 24/25/30p);4096 x 2160 (4096 x 2160 48/50p)
Still Photography Modes: Single Shot;Burst Shooting: 3/5/7/10/14 frames;Auto Exposure Bracketing (AEB): 3/5 bracketed;frames at 0.7EV Bias;Interval: 2/3/5/7/10/15/30/60 s
Video Recording Modes: H.265;C4K:4096 x 2160 24/25/30p @100Mbps;4K:3840 x 2160 24/25/30p @100Mbps;2.7K:2720 x 1530 24/25/30p @65Mbps;2720 x 1530 48/50/60p @80Mbps;FHD:1920 x 1080 24/25/30p @50Mbps;1920 x 1080 48/50/60p @65Mbps;1280 x 720 48/50/60p @35Mbps. H.264;C4K:4096 x 2160 24/25/30/48/50/60p @100Mbps;4K:3840 x 2160 24/25/30/48/50/60p @100Mbps;2.7K:2720 x 1530 24/25/30p @80Mbps;2720 x 1530 48/50/60p @100Mbps;FHD:1920 x 1080 24/25/30p @60Mbps;1920 x 1080 48/50/60/120p @80Mbps;HD: 1280 x 720 24/25/30p @30Mbps;1280 x 720 48/50/60/120p @45Mbps
Video Storage Bitrate: 100 Mbps
Supported File Systems: FAT32 (32 GB Max); exFAT (> 32 GB)
Photo: JPEG, DNG (RAW), JPEG + RAW
Video: MP4/MOV (AVC/H.264;HEVC/H.265)
Supported SD Cards: Micro SD, Max Capacity: 128GB. Write speed 15MB/s Min., class 10 or UHS-1 rating required
Operating Temperature: 32°to 104°F (0°to 40° C)
|
|
Dimensions
|
Weight (Battery & Propellers Included): 1388 g
Diagonal Size (Propellers Excluded): 350 mm
|
|
Package Contents
|
1 X Aircraft
1 X Remote Controller ( without screen )
4 X Propeller Pairs
1 X Intelligent Flight Battery
1 X Battery Charger
1 X Power Cable
1 X Gimbal Clamp
1 X USB OTG Cable
1 X Micro USB Cable
1 X Micro SD Card(16GB)
1 X Carrying Case
1 X English Manual
|
