2.2 Inch TFT LCD Touch Screen Expansion Shield with Touch Pen for Arduino

Highlights

This is a 2.2 inch TFT touch screen expansion board using standard Arduino Shield interface and it has good compatibility. It integrates a 2.2-inch touch screen, I2C temperature sensor, TF card holder, level conversion circuit, and the secondary development is easy.

With GPRS module, you can design your Arduino phone.

With NFC reader module, you can create access control systems with the photos show.

With voltage and current sensor, you can make oscilloscope.

Can use it directly to display characters, graphics and BMP format images. And touch controlling is available;

Compatibility: As the SD card is connected to SPI pins of ICSPinterface, compatible with Arduino UNO R3 / Arduino Mega2560 / Arduino Leonardo

Use the A0 ~ A3 pins, D4 ~ D13 pins. AndI2C interface, D0 / D1 / D2 / D3 is available, please refer to the product schematics for the details.

It leads out the I2C interface of Arduino board, it can connect to the DS1307 RTC module, BMP280 barometric pressure sensor module, AP3216 digital ambient light proximity sensor module.

It leads out the RX / TX interface, it can connect to serial ESP-07 / ESP-12 Wi-Fi module, serial MP3 module, serial GPRS module.

Onboard Micro SD slot, support Micro SD / TF Card;

Onboard LM75 temperature sensor: default I2C address is 0X48, scale is -55 ~ 125'C

Very suitable for digital photo frame, oscilloscope, function generator, detection system monitor

Specification
