General |
Main Procesor |
Sensor |
GM8136S |
Image sensor |
Image sensor |
1/4 "color CMOS sensor(H42) |
Display resolution |
1280*720 (1MP) |
Lens |
f: 3.6mm, 1.3MP |
Visual angle |
H:60.5°; V:37°; D:72° |
Minimum illumination |
0.01Lux |
Audio |
Input/output |
Built-in microphone and speaker |
Audio compression |
AAC |
Video |
Video compression |
H.264 |
Lighting frequency |
50Hz, 60Hz |
Image frame rate |
Max 30fps |
Image resolution |
1MP |
Image adjustment |
Brightness, Contrast, Saturation, Sharpness |
White balance, BLC |
Automatically |
Night vision |
1 dot matrix infrared lights, IR distance: 15meters |
Internet |
Wireless networks |
2.4G WIFI(IEEE802.11b/g/n),Built in PCB board 2DB antenna |
Ethernet |
10/100Mbps |
Protocols |
TCP/IP,UDP/IP,HTTP,DHCP,RTMP,MUTP |
IP address |
Static IP address and dynamic IP address |
RF |
Support connecting RF devices |
No |
Intelligence |
Face detection |
No |
POE |
POE |
No |
Pan&Tilt |
Pan&Tilt |
Horizontal:350°& Vertical:100° |
Alarm |
Alarm detection |
Motion detection |
Alarm linkage |
Snapshot, audio/video record |
Alarm notification |
Real-time App push notifications |
RF Peripheral |
No |
Interface |
Power |
DC 5V / 2A(Europen,UK,USA type for option) power consumption <7W |
Buttons |
A reset hole, a FN button |
Network interface |
RJ45 |
Others |
Adjustable lens |
No |
LED instructions |
Network signal/function indicator |
Video storage |
Micro SD(Max 64GB),cloud box |
Environment |
Work temperature |
-10° ~ 55°C (14°F ~ 131°F) |
Work humidity |
10% ~ 80% (No condensation) |
Storage temperature |
-10°C ~ 60° (14°F ~ 140°F) |
Storage humidity |
0% ~ 90%(No condensation) |
Color |
Color |
White and black |
Specifications |
Size(L*W*H) |
85(L)X85(W)x120(H)mm |
Weight |
267g(not include rack) |
Certification |
Certificate |
RoHS,CE,FCC,NCC |
