Highlights
One Key Switch Engraving/Cutting Mode
The A40 Pro V2 adopts a new laser design, which can switch between 24W and 48W output power with one key by a physical button. For different work of engraving and cutting open different modes, A40 Pro V2 can be both fine engraving and powerful output
48W Output Power
The ATOMSTACK A40 Pro V2 laser engraver and cutter machine with 48000mW output power effortlessly passes through 18 mm Wood & 0.1 mm stainless steel sheets & 9mm MDF & 7nm Acrylic in a single pass at a faster speed up to 500mm/s! It is ideal for small businesses and home use
Safety Laser
The laser engraving machine comes with various compliance certifications. Class IV laser contains protective glass and is equipped with safety glasses for safe use. Please refer to the manual before use. During the carving process, please stay away from flammable materials and do not leave. If you have any questions, please contact our professional technical guidance.
Strong and Easy to Install Structure
The full aluminum alloy anodized structure design makes the machine more solid and durable, and improves the accuracy of engraving. The whole structure supports quick installation design. Users can generally install the machine within 20-30min.
Specification
| General | Brand: ATOMSTACK Type: Laser Engraver Model: A40 Pro V2 |
| Specification | Engraving Size: 395 x 385mm (15.55" x 15.16") Engravable Materials: Wood, bamboo, cardboard, plastic, leather, PCB board, aluminum oxide, non-reflective electroplated and lacquer-coated metals, 304 mirror stainless steel, glass, ceramic, cotton fabric, slate. Cuttable Materials: Cardboard, non-woven fabric, wood board, acrylic, certain thin plastic sheets, sponge. Total Power: 210W Laser Power: 180W (in cutting mode) Laser Output Power: 40-48W Laser Wavelength: 455±5nm Engraving Precision: 0.01mm Focusing Method: Fixed-focus laser, no need for manual focusing Limit Switches: 2 (1 on X-axis, 1 on Y-axis) Laser Protection Shield: The laser has a protective shield that safeguards the user's eyes, eliminating the need for additional safety glasses. It also prevents pets from interacting with the laser spot. Operating Software: LaserGRBL, LightBurn, supports Win XP / Win 7 / Win 8 / XP / Win 10 Supported File Formats: NC, BMP, JPG, PNG, DXF Data Transmission Method: USB connection Power Supply: Universal standard power input: 100-240V AC, 50/60HZ, Output: 24V 9A Certifications: CE, FCC, RoHS, FDA, PSE |
| Weight & Size | Product Weight: 15kg Package Weight: 16kg Package Size(L x W x H): 59x56x16cm |
| Package Contents | 1 x Laser Engraver 1 x Laser Module 1 x Air Pump 1 x Power Cable and Power Adapter 1 x User Manual |
