Aircraft
Takeoff Weight [1]: 249 g
Dimensions: Folded: 140×82×57 mm (L×W×H)
Unfolded: 160×202×55 mm (L×W×H)
Unfolded (with propellers): 245×290×55 mm (L×W×H)
Diagonal Distance: 213mm
Max Ascent Speed: 4m/s (S Mode)
2m/s (P Mode)
1.5m/s (C Mode)
Max Descent Speed: 3 m/s (S Mode)
1.8m/s (P Mode)
1m/s (C Mode)
Max Speed (near sea level, no wind): 13m/s (S Mode)
8m/s (P Mode)
4m/s (C Mode)
Max Service Ceiling Above Sea Level: 3000m
Max Flight Time: 30minutes (measured while flying at 14 kph in windless conditions)
Max Wind Speed Resistance: 8m/s (Scale 4)
Max Tilt Angle: 30° (S Mode)
20° (P Mode)
20° (C Mode)
Max Angular Velocity: 150°/s (S Mode)
130°/s (P Mode)
30°/s (C Mode)
Operating Temperature Range: 0° to 40°C (32° to 104°F)
Operating Frequency: Model MT1SS5: 5.725-5.850GHz
Model MT1SD25: 2.400-2.4835GHz, 5.725-5.850GHz
Transmission Power (EIRP): Model MT1SS5
5.8GHz: <30dBm (FCC); <28dBm (SRRC)
Model MT1SD25
2.4GHz: <19 dBm (MIC/CE)
5.8GHz: <14 dBm (CE)
GNSS: GPS+GLONASS
Hovering Accuracy Range: Vertical: ±0.1 m (with Vision Positioning), ±0.5 m (with GPS Positioning)
Horizontal: ±0.1 m (with Vision Positioning), ±1.5 m (with GPS Positioning)
Gimbal
Mechanical Range: Tilt: -110° to 35°
Roll: -35° to 35°
Pan: -20° to 20°
Controllable Range: Tilt: -90° to 0° (default setting) -90° to +20° (extended)
Stabilization: 3-axis (tilt, roll, pan)
Max Control Speed (tilt): 120°/s
Angular Vibration Range: ±0.01°
Sensing System
Downward: Operating Range: 0.5-10 m
Operating Environment: Non-reflective, discernable surfaces
Diffuse reflectivity (>20%)
Adequate lighting (lux>15)
Camera
Sensor: 1/2.3” CMOS
Effective Pixels: 12MP
Lens: FOV: 83°
35 mm Format Equivalent: 24mm
Aperture: f/2.8
Shooting Range: 1 m to ∞
ISO Range: Video:
100-3200 (Auto)
Photo:
100-1600 (Auto)
100-3200 (Manual)
Shutter Speed: Electronic Shutter: 4-1/8000s
Still Image Size: 4:3: 4000×3000
16:9: 4000×2250
Still Photography Modes: Single shot
Interval: 2/3/5/7/10/15/20/30/60s
Video Resolution: 2.7K: 2720×1530 25/30p
FHD: 1920×1080 25/30/50/60p
Max Video Bitrate: 40 Mbps
Supported File System: FAT32(≤32 GB)
exFAT(>32 GB)
Photo Format: JPEG
Video Format: MP4 (H.264/MPEG-4 AVC)
Remote Controller & Video Transmission
Operating Frequency: Model MR1SS5: 5.725-5.850 GHz
Model MR1SD25: 2.400-2.4835 GHz, 5.725-5.850 GHz
Max Transmission Distance (unobstructed, free of interference): Model MR1SS5
5.8 GHz: 4000 m (FCC); 2500 m (SRRC)
Model MR1SD25
2.4 GHz: 2000 m (MIC/CE)
5.8 GHz: 500 m (CE)
Operating Temperature Range: 0°to 40°C (32° to 104°F)
Transmission Power (EIRP): Model MR1SS5
5.8 GHz: <30 dBm (FCC); <28 dBm (SRRC)
Model MR1SD25
2.4 GHz: <19 dBm (MIC/CE)
5.8 GHz: <14 dBm (CE)
Battery Capacity: 2600 mAh
Operating Current/Voltage: 1200mA 3.6V (Android)
700mA 3.6V (iOS)
Supported Mobile Device Size: Max length: 160 mm
Max thickness: 6.5-8.5 mm
Supported USB Port Types: Lightning, Micro USB (Type-B), USB Type-C
Video Transmission System: Enhanced Wi-Fi
Live View Quality: 720p/30fps
Max. Bitrate: 4Mbps
Latency (depending on environmental conditions and mobile device): 170-240 ms
Charger
Input: 100-240V,50/60Hz,0.5A
Output: 12V 1.5A/ 9V 2A/5V 3A
Rated Power: 18W
Intelligent Flight Battery
Capacity: 2400mAh
Voltage: 7.2V
Max Charging Voltage: 8.4V
Battery Type: Li-ion 2S
Energy: 17.28 Wh
Net Weight: 100g
Charging Temperature Range: 5°to 40°C (41° to 104°F)
Max Charging Power: 24W
Intelligent Flight Battery (1100 mAh)
Capacity: 1100 mAh
Voltage: 7.6 V
Max Charging Voltage: 8.7 V
Battery Type: LiPo 2S
Energy: 8.36 Wh
Net Weight: 50 g
Charging Temperature Range: 5°to 40°C (41° to 104°F)
Max Charging Power: 18W
APP
Name: DJI Fly
Required Operating System: iOS v10.0 or later Android v6.0 or later
Supported SD Cards
Supported SD Cards: UHS-I Speed Class 3 or above is required. A list of recommended microSD cards can be found below.
Recommended microSD Cards: 16 GB: SanDisk Extreme, Lexar 633x
32 GB: Samsung Pro Endurance, Samsung Evo Plus, SanDisk Industrial, SanDisk Extreme V30 A1, SanDisk Extreme Pro V30 A1, Lexar 633x, Lexar 667x
64 GB: Samsung Pro Endurance, Samsung Evo Plus, SanDisk Extreme V30 A1, Lexar 633x, Lexar 667x, Lexar 1000x, Toshiba EXCERIA M303 V30 A1, Netac Pro V30 A1
128 GB: Samsung Pro Plus, Samsung Evo Plus, SanDisk Extreme V30 A1, SanDisk Extreme Plus V30 A1, Lexar 633x, Lexar 667x, Lexar 1000x, Toshiba EXCERIA M303 V30 A1, Netac Pro V30 A1
256 GB: SanDisk Extreme V30 A1
Footnotes
Footnotes: 1. Aircraft takeoff weight (includes battery and propellers). Registration not required in some countries and regions. Check local rules and regulations before use. These specs have been determined through tests conducted with the latest firmware. Firmware updates can enhance performance, so updating to the latest firmware is highly recommended.
|
