Camera:
FOV: 120°
Max Still Photo Resolution: 2560×1440
Max Video Resolution: FHD: 1080/30fps
HD: 720/30fps
Max Video Bitrate: 16 Mbps
Photo Format: JPEG
Video Format: MP4
Sensor: CMOS 1/4″; Effective pixels: 5 MP
Operating Temperature Range: -10 to 40 Celsius (14 to 104 Fahrenheit)
Narrow Infrared Units:
Effective Range [1]: 6 m (in indoor lighting conditions)
Effective Area: Varies from 10 degree to 40 degree
Effective area decreases as distance from the target increases.
Wide Infrared Units
Effective Range [1]: 3 m (in indoor lighting conditions)
Effective Width: 360 degree (in indoor lighting conditions)
Hit Detector:
Detection Requirements
For the Hit Detector to be activated, the following conditions must be met: Gel bead diameter ≥ 6mm, launching speed ≥20m/s, and the angle between the hit direction and hit detector plane is no less than 45 degree.
Maximum Detection Frequency: 15 Hz
S1:
Weight: Approx. 3.3 kg
Dimensions: 320×240×270 mm (length × width × height)
Chassis Speed Range: 0-3.5 m/s (forward)
0-2.5 m/s (backward)
0-2.8 m/s (sideways)
Max Chassis Rotational Speed: 600 degree/s
M3508I Brushless Motor:
Max Rotational Speed: 1000 rpm
Max Torque: 0.25N*m
Max Output Power: 19 W
Operating Temperature Range: -10 to 40 Celsius (14 to 104 Fahrenheit)
Driver: FOC
Control Method: Closed-loop speed control
Protection:
Overvoltage protection
Overtemperature protection
Soft-start
Short-circuit protection
Chip and sensor anomaly detection
Blaster
Controllable Launching Frequency: 1-8/s
Max Launching Frequency: 10/s
Initial Launching Speed: Approx. 26 m/s
Average Load: Approx. 430
Gimbal
Controllable Range: Pitch: -20 degree to +35 degree
Yaw: ±250 degree
Mechanical Range: Pitch: -24 degree to +41 degree
Yaw: ±270 degree
Max Rotational Speed: 540 degree/s
Vibration Control Precision (on the flat surface and with the Blaster idle): ±0.02 degree
Intelligent Controller
Latency (depending on environmental conditions and mobile device)
Connection via Wi-Fi: 80-100ms
Connection via Router: 100-120ms(unobstructed, free of interference)
Live View Quality: 720p/30fps
Max Live View Bitrate: 6 Mbps
Operating Frequency: 2.4 GHz, 5.1 GHz, 5.8 GHz
Operating Mode: Connection via Wi-Fi, Connection via Router
Max Transmission Distance (unobstructed, free of interference)
Connection via Wi-Fi: FCC, 2.4 GHz 140 m, 5.8 GHz 90 m
CE, 2.4 GHz 140 m, 5.8 GHz 70 m
SRRC, 2.4 GHz 130 m, 5.8 GHz 130 m
MIC, 2.4 GHz 140 m
Connection via Router: FCC, 2.4 GHz 180 m, 5.8 GHz 300 m
CE, 2.4 GHz 180 m, 5.1 GHz 100 m
SRRC, 2.4 GHz 180 m, 5.8 GHz 300 m
MIC, 2.4 GHz 170 m, 5.1 GHz 180 m
Transmission Power (EIRP): 2.400-2.4835 GHz
FCC: ≤30 dBm
SRRC: ≤20 dBm
MIC: ≤20 dBm
5.170-5.25 GHz
FCC: ≤30 dBm
SRRC: ≤23 dBm
MIC: ≤23 dBm
5.725-5.850 GHz
FCC: ≤30dBm
SRRC: ≤30dBm
Transmission Standard: IEEE802.11a/b/g/n
Intelligent Battery
Capacity: 2400 mAh
Nominal Charging Voltage: 10.8 V
Maximum Charging Voltage: 12.6 V
Battery Type: LiPo 3S
Energy: 25.92 Wh
Weight: 169 g
Operating Temperature Range: -10 to 40 Celsius (14 to 104 Fahrenheit)
Charging Temperature Range: 5 to 40 Celsius (41 to 104 Fahrenheit)
Maximum Charging Power: 29 W
Battery Life in Use: 35 minutes (measured at a constant speed of 2 m/s on a flat surface)
Battery Life on Standby: Approx. 100 minutes
Charger
Input: 100-240 V, 50-60Hz, 1A
Output: Port: 12.6 V=0.8A or 12.6 V=2.2A
Voltage: 12.6 V
Rated Voltage: 28 W
Gel Bead
Diameter: 5.9-6.8 mm [2]
Weight: 0.12-0.17 g [2]
App:
App
RoboMaster
iOS
iOS 9.0 or later
Android
Android 5.0 or later
Router:
Recommended Routers
TP-Link TL-WDR8600; TP-Link TL-WDR5640 (China)
TP-Link Archer C7; NETGEAR X6S (International)
Recommended outdoor power supply solution for routers
Laptop Power Bank (match the input power of the router)
MicroSD card:
Supported SD Cards
Supports microSD cards with a capacity up to 64GB
Others:
Notes: 1. Use of the infrared units will be affected in outdoor or infrared-intensive environment.
2. The gel beads will swell to a usable size after being soaked in water for four hours.
|
