Highlights
- 1/4" 1.0 Megapixel CMOS, Max image Resolution 1280*720@25fps wifi IP camera
- H.264 Main Profile @ level 3.0 coding, Real time H.264 dual-stream encoding, resolution, frame rate, bit rate adjustable
- Support Color/BW mode converting, IR-CUT Filter ,built in wifi
- Build in Motion Detection,
- Auto-retrieve function and auto-connection network
- Support Plug-and-Play, including PC surveillance platform and mobile client, Easy to remote
- Integrated ONVIF standard, Compatibility with third-party ONVIF platform software
- IP65 Rated Waterproof, indoor use
|
Model |
IPCC-H04 |
|
Hardware |
|
|
Processor |
HI3518C |
|
Sensor |
1/4" 1.0 Megapixel CMOS |
|
Lens |
4mm lens |
|
IR LED |
36 IR LEDs, IR Distance 10~40m |
|
Day/Night |
IR-CUT |
|
Min. Illumination |
0.1lux; 0 lux with IR on |
|
Max S/N Ratio |
50dB |
|
Video |
|
|
Compression |
H.264 |
|
image |
main stream: 1280x960@1-25fps 1280x720@1-25fps sub stream: 640x480@1-25fps 320x240@1-25fps |
|
Bit Rate |
128~4096kbps, Supports CBR/VBR |
|
Image Control |
|
|
Auto Image Control |
AE, AWB |
|
Audio |
|
|
Compression |
G.711-A |
|
Bit Rate |
64kbps/128kbps |
|
Talkback |
support |
|
Network |
|
|
Protocol |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, FTP, UPNP |
|
Compliance |
ONVIF 2.1(1.02 backward compatible) |
|
PC Client and Browser |
ISS, IE6.0 and above |
|
Mobile phone |
Iphone, ipad, Android |
|
WIFI |
support |
|
WIFI Encryption |
WAP, WAP2 |
|
Interface |
|
|
LAN |
1 RJ45 10M/100M Ethernet port |
|
General |
|
|
Working Temperature |
-10~ +55centigrade |
|
Working Humidity |
0% - 90% |
|
Protection Level |
IP65 indoor use |
|
Power Supply |
DC 12 V/1A |
|
Power Consumption |
Maximum 6w |
|
Dimensions |
80*80*60mm |
|
Weight |
1.0kg |
|
Approvals |
CE , FCC, RoHS |
What's in the box?
- 1 * IP Camera
- 1 * Power Adapter
- 1 * CD
- 1 * Set of Mounting Screws
- 1 * User Manual
