Flight Control
MPU6000
CPU: STM32F405RGT6
Input Voltage: 2-4S Lipo
Built-in Betaflight OSD to adjust PID
BEC Output: 5V@2A
Size: 20x20mm board,2mm mounting holes (M3)
Weight: 4g
Support Subs/PPM/DSMX receiver
4in1 35A ESC
Input Voltage: 2-4S Lipo battery
Constant Current: 35A
Peak Current: 38A
BEC Output: NO
Firmware: BLhelis
Size: 27x27mm (main board) 27x31mm (including pad)
Installing Hole: 20x20mm,M2
Weight: 4g
MOS Tube: TOP QUALITY MOSFET
Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150/300/600, forward and reverse
Motor: 1408 3800KV
Prop: Gemfan 3inch
Camera
Brand: Runcam
Item Name: Hybrid
Field of View (FOV): HD Recording FOV 145° (FPV FOV: 150° @ 4: 3)
Video Resolution: 4K@30fps/2.7K@60fps/2.7K@50fps/1080P@120fps/1080P@100fps/1080P@60fps/1080P@50fps
Video File Format MP4
TV Mode NTSC (720*480)/PAL (720*576) Switchable
Mounting Hole Distance 20*20mm
PCB Size 29*29mm
Lens Module Size 19*25mm
Lens Specs HD M10; Analog M8
Power Input DC 5-20V
Working Current 480mA @5V / 140mA @12V
Weight 18g
VTX
Output Power: 25mW/200mW/500mW switchable
Control Mode: button OR Channel changes and Pitmode setting
BAT: 7-26V,BEC 5V-1A
145mA----500mW
Video System: NTSC/PAL
Antenna: IPEX
Frequency: 5.8GHz 5 bands 48channels
Weight: 3.2g
Mounting Hole: 20mm x 20mm
Antenna
Weight: 7.4g
Size: 60mm x 17mm
Gain: 2.5dbi
Axial Ratio: <1.0 (near perfect)
Bandwidth: 5.5GHz-6.0GHz
Radiation Efficiency: 98%
VSWR: <=1.2
Connector: SMA
Works great as both a transmitting or receiving antenna
Compatible with other styles of 5.8GHz RHCP antennas
|
and more
