Highlights
- 32 Channel, 4 frequency band wireless receiving
- 2 Buttons for channel and band exchange individually
- 2 number display, timely locate the current receiving frequency and band
- When power on, storage memory shows channel and frequency of the last time.
- Two-way video and audio signal output(video: PAL, NTSC, CECAM Audio: 6.5MHz)
- 5dB sensitivity gain more than normal receiver
- Wide dynamic power supply(7-24V)
- Newly LOED display, can show the current working state correctly
- Auto search, can find the needed channel by one press
Specification
| General | |
|---|---|
| Type | Transmitter |
| Model | Skyzone R600 |
| Frequency | 5.8G |
| Channel | 32CH |
| Connector | SMA |
| Receiving | Receiving Sensitivity: -95dBm Receiving Frequency: ISM 5.8GHz 32CH |
| Power Supply | Power Supply Voltage: DC 7-26V Supply Current: 130mA RF Input Matching: 50ohm SMA |
| Video | Video Output Voltage: 1.0Vp_p 75Ω |
| Audio | Audio Output Voltage: 1.0Vp_p 10KΩ |
| Frequency | FR1(A) 5865M,5845M,5825M,5805M,5785M,5765M,5745M,5725M FR2(R) 5658M,5695M,5732M,5769M,5806M,5843M,5880M,5917M FR3(E) 5705M,5685M,5665M,5645M,5885M,5905M,5925M,5945M FR4(F) 5740M,5760M,5780M,5800M,5820M,5840M,5860M,5880M |
| Dimension/Weight | Dimension: 95 x 54 x 15mm Weight: 100g |
| Package Contents | |
| 1 x transmitter | |
| 1 x antenna | |
| 1 x cable | |
