Highlights
- Supports both Wireless Access Point and Wireless Repeater modes.
- Enables wired network wireless ready through the LAN port.
- Extends the range of your WLAN network easily, cover wlan signal in more places.
- Access to the Internet for computers located on the edge or outside of the range of your access point.
- Shares large files, printing and storage quickly and reliably in wider range in your home or office.
- Complies with IEEE 802.11n, IEEE 802.11g, IEEE 802.11b standards.
- Supports Wifi Protection Setup function (WPS).
- WEP, WPA, and WPA2 to ensure network security from unauthorized access.
- Support 2.4GHz WLAN networks, Provides up to 300Mbps transmission rates.
- Wireless Auto-channel selection.
- User-friendly web-based wizard and easy hardware setup. Portable, no need of external power adaptor.
|
Protocol/Standards |
Wireless IEEE802.11n, IEEE802.11b/g, |
|
Wireless Signal Rates |
11n: Up to 300Mbps(dynamic) |
|
Frequency Range |
2.4-2.4835GHz |
|
Wireless Transmit Power |
14 ~17 dBm (Typical) |
|
Modulation Technology |
11n: BPSK, QPSK, 16QAM, 64QAM with OFDM |
|
Receiver Sensitivity |
270M: -68dBm@10% PER |
|
Antenna |
3dBi PCBA Antennas |
|
WPS Function |
Yes |
|
Security |
Wireless: 64/128-bit WEP, WPA, WPA2 |
|
Power Supply Unit |
100v - 240v ac |
|
Power Consumption |
Less than 4W |
|
Max Current |
0.12A |
|
Transmission Rate |
Up to 300Mbps |
|
Operating temperature |
0°C~40°C (32°F~104°F) |
|
Storage temperature |
-40°C~70°C (-40°F~158°F) |
|
Operating humidity |
30% to 90% Relative Humidity (Non-Condensing) |
|
Storage humidity |
30% to 95% Relative Humidity (Non-Condensing) |
What's in the box?
- 1 x Network ethernet Cable
- 1 x User Manual
