Highlights
Qualcomm 6-Core Enterprise-Grade
Enterprise-level professional chip P08071A, equipped with Qualcomm 4-core 64 bit A53 CPU+2 core network acceleration engine. The professional chip runs more stable.
OFDMA
OFDMA significantly improves the transmission efficiency of multiple devices working at the same time and reduces the delay.
MU- MIMO
MU-MIMO allows multiple antennas of a router to serve multiple devices at the same time.
Support Beamforming Technology, Directional Enhanced Signal
Beamforming technology, which can automatically detect the position of mobile phones, computers, and other terminals in the network, enhance the signal of the location, make Wi-Fi effective coverage wider, and the signal quality is more stable.
Specification
| CPU | IPQ8071A 4Core A53 1GHz CPU |
| Network acceleration engine | Dual core 1.7GHz NPU |
| ROM | 256MB |
| Memory | 512MB |
| 2.4G Wi-Fi | 2x2 (IEEE802.11ax, 574Mbps) |
| 5G Wi-Fi | 4x4 (IEEE802.11ax, 2402Mbps) |
| Antenna | 6*External high gain antennas 1*AloT Antenna |
| Heat dissipation | Natural heat dissipation |
| Physical interface | 1*10/100/1000 WAN (Auto MDI/ MDIX) 3*10/100/1000 LAN (Auto MDI/ MDIX) |
| LED Indicator light | 1*SYSTEM indicators 1*INTERNET indicators 4*Network ports 1*AIoT light |
| Reset button | 1*Reset button |
| Power input interface | 1*Power input interface |
| Wireless standard | IEEE 802.11a/b/g/n/ac/ax, IEEE802.3/3u/3ab |
| Certification standards | GB/T9254-2008; GB4943.1-2011 |
| Dual band | 2.4GHz, 5GHz |
| Wireless channel | 2.4GHz Channel: 1,2,3,4,5,6,7,8,9,10,11,12,13 5GHz Channel: 36,40,44,48,149,153,157,161,165 |
| Modulation Mode | 11b: DSSS: DBPSK(1Mbps), DQPSK (2Mbps), CCK (5.5/11Mbps) 11a/g: OFDM: BPSK (6/9Mbps), QPSK (12/18Mbps), 16QAM(24/36Mbps), 64QAM(48/54Mbps) 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM. Rate set: MCS0~MCS15 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM. Rate set: MCS0~MCS9 (4 streams supported) 11ax: MIMI-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM. Rate set: MCS0~MCS11(4 streams supported) |
| Operating system | Intelligent router operating system MiWiFi ROM based on OpenWRT deep customization |
| Wireless security | WPA-PSK / WPA2-PSK/ WPA3-SAE encryption, wireless access control (black and white list), hidden SSID, intelligent anti-scratch network |
| Management application | Support Web, Android, iOS |
Working environment |
Working temperature: 0~40ºC |
| Storage temperature: 10%~90%RH Non-condensing | |
| Working humidity: -40~70ºC | |
| Storage humidity: 5%~90%RH Non-condensing |
Package Included:
1 X Xiaomi AIoT router AX3600(Global Version)
1 X User manual (English Version)
1 X Power line (12V/1.5A)
1 X Network cable
