Highlights

  • What’s Orange Pi mini? It’s an open-source single-board computer. It can run Android 4.4 , Lubuntu, Debian, Rasberry Pi Image, it uses the AllWinner H3 SoC, and has 1GB DDR3 SDRAM.

Specification

What can I do with Orange Pi Mini?
Build…

  • A computer
  • A wireless server
  • Games
  • Music and sounds
  • HD video
  • A speaker
  • Android
  • Scratch
  • Pretty much anything else, because Orange Pi Plus is open source

Who’s it for?

Orange Pi Plus is for anyone who wants to start creating with technology – not just consuming it. It's a simple, fun, useful tool that you can use to start taking control of the world around you.

Hardware specification
CPU H3 ARM Cortex-A7 quad-core,256KB L1 cache 1MB L2 cache
GPU Mali400MP2 GPU @600MHz
Supports OpenGL ES 2.0
Memory (SDRAM) 1GB DDR3 (shared with GPU)
Onboard Storage TF card (Max. 64GB) / MMC card slot , up to 2T on 2.5 SATA disk
Onboard Network 10/100/1000 Ethernet RJ45, WIFI onboard
Video Input A CSI input connector allows for the connection of a designed camera module
Audio Input MIC,LINEIN,FMIN
Video Outputs HDMI, CVBS
Audio Output 3.5 mm Jack and HDMI
Power Source USB OTG input,DC input
USB 2.0 Ports Four USB 2.0 HOST, one USB 2.0 OTG
Buttons Power button: Next to Reset button
UBoot button (optional): Behind HDMI connector
Low-level peripherals 40 Pins Header,compatible with Raspberry Pi B+

28×GPIO, some of which can be used for specific functions

including UART, I2C, SPI, PWM, CAN, I2S, SPDIF, LRADC,

ADC, LINE-IN,FM-IN,HP-IN.

GPIO(1x3) pin UART,ground.
LED Power Key & RJ45
Key IR input,UBOOT,POWER
Supported OS Android Lubuntu, Debian, Rasberry Pi Image
Interface definition
Product size 94 mm × 59mm
Weight 45g
Orange Pi™ is a trademark of the Shenzhen Xunlong Software CO,Limited

342382342382342382342382342382

What's in the box?

  • 1 x Orange pi mini
