Highlights
Strong Cutting Force
It can cut 18mm acrylic, 12mm MDFM density board, 30mm pine board, and 0.3mm stainless steel sheet.
New Movement Structure
In order to ensure high-speed and stable operation, the machine adopts a new low center of gravity double axis guide rail structure, stable and high-speed silent operation, suitable for heavy engraving and cutting work.
Offline Work
The product is equipped with the second generation intelligent motherboard and control screen, which can get rid of computers and mobile phones and complete work offline.
Standard Large Flow Air Assist
The maximum 60L/min large flow air assist makes the cutting work flawless, and the cutting line surface does not yellow, extending the service life of the laser.
Multiple Use Scenarios
Can work on reflective metal, ceramic, and black acrylic material, support woodworking creation, painting art, DIY creation, billboard, metal marking, and clothing design.
Fast Accuracy
Under the high-speed operation of 400mm/s, an accuracy of 0.01mm can be maintained.
Dual Mode Focus Length
Manual focus and automatic focus, 8 seconds to complete the focus.
Automatic Flame Alarm
When the flame spot wavelength point in the working area is detected to exceed 35%, the alarm will be triggered and the work will stop an accurate and high speed.
Intelligent Cooling System
Open the double-layer air hood air assist, automatically open the air assist when cutting better heat, better cutting effect.
Power Off Continued Carving Function
Power off during the creation, when the call to continue to work unfinished creation.
Specification
| General | Brand: ATOMSTACK Type: Laser Engraving Machine Model: A70 PRO Color: Black |
| Specification | Engraving Size: 500*400mm Working Principle: Engraving / Cutting Engraving Materials: Wood, bamboo, cardboard, plastic, leather, PCB board, aluminum oxide, non-reflective electroplated and painted metal, 304 mirror stainless steel, dark glass, ceramics, cotton, slate; Cutting Materials: Thin steel plate, cardboard, non-woven fabric, wood, black acrylic, more thin plastic sheets, sponge; Input Power: 360W Output Power: 70-77W, 35-39W Maximum Speed: 400mm/s (24000mm/min) Laser Wavelength: 455±5nm Engraving Accuracy: 0.01mm Repetition Accuracy: 0.1mm Spot Size: 0.12*0.18mm (70W) / 0.08mm*0.12mm (35W) Transmission Method: USB transmission Focus Adjustment Method: Automatic focus + manual focus Screen Control: 4.3 inches Connection Support: Type-C, mobile WiFi, touch screen Support Systems: IOS, Android, Windows, Mac Operating Software: LaserGRBL, LightBurn, AtomStack Studio Air Flow Rate: 0-60 L/min infinitely adjustable Power Supply: Input 100-240V AC, 50/60Hz, output 12V 5A |
| Weight & Size | Product Weight: 13.8kg Package Weight: 15.4kg Product Size(L x W x H): 68.3x71x21.5cm Package Size(L x W x H): 80x54x23cm |
| Package Contents | 1 x Upper Support Bar Component 1 x Bottom Component 1 x Air Pump 1 x Power Adapter 1 x Laser 1 x Display 1 x Fixed Focus Film 1 x Glasses 1 x Power Cable 1 x Y-Axis Left Slide Rail Component 1 x Lower Support Bar Component 1 x Y-Axis Right Slide Rail Component |
