Highlights
- Analog Test Shield is an Arduino expansion board, provides functionalities of both AD acquisition and DA output. It's an easy way to know about the analog electronics
- Arduino standard interfaces, compatible with Arduino boards like Arduino UNO, Leonardo, NUCLEO, XNUCLEO
- Rotate the potentiometer to adjust AD sampling data
- Onboard 12bit DAC MCP4725, outputs required wave form
- Demonstrate the DAC/PWM effects via LED and speaker
- Development Resources
- User manual
- Schematic
- Demo code
- Datasheet
Specification
| General | |
|---|---|
| Type | Analog Test Shield |
| Quantity | 1 Piece |
| Compatible | Arduino Development AD/DA |
| Wiki | www.waveshare.com/wiki/Analog_Test_Shield |
