Highlights
High-Resolution Thermal Imaging
Powered by a 256×192 thermal sensor and a 1024×768 Micro-OLED display, it delivers sharp, highly detailed heat signatures for clear visibility in both day and night conditions.
8× Digital Zoom for Extended Reach
8× digital zoom enhances your viewing range up to 100 meters, allowing you to detect, identify, and track targets with greater precision at a distance.
Large 3.2" Micro-OLED Display
The 3.2-inch high-contrast Micro-OLED screen provides exceptional image clarity and depth, ensuring fast, intuitive target recognition even in complex environments.
Built-in Wi-Fi & Smart App Control
Integrated Wi-Fi enables real-time thermal streaming, remote device control, and instant photo/video sharing directly to iOS and Android devices.
Long-Lasting Battery & Ample Storage
A 2000mAh rechargeable battery delivers over 3 hours of continuous operation, while 32GB of built-in storage lets you record hours of footage without needing external memory cards.
Specification
| Brand | GTGUARD |
| Type | Thermal Imaging Monocular |
| Model | B215AL |
| Color | Black |
| Detector Type | Vanadium Oxide Uncooled Infrared Focal Plane Array (VOx UFPA) |
| Detector Resolution | 256 × 192 |
| Pixel Pitch | 12 μm |
| Spectral Response | 8 μm ~ 14 μm |
| NETD | ≤ 45 mK |
| Objective Lens | 15 mm f/1.0, Ø 22 mm |
| Field of View | 11.69° × 8.78° ± 5% |
| Magnification | 1x, 2x, 4x, 8x digital zoom |
| Display | 3.2", 1024 × 768 LCD |
| Laser Wavelength | 905 nm ± 10 nm @ 25 °C |
| Ranging Capability | ≥ 600 m (visibility ≥ 10 km, humidity ≤ 60%) |
| Ranging Blind Zone | ≤ 5 m |
| Ranging Accuracy | ≤ ± 1 m (≤ 300 m), ≤ ± 2 m (> 300 m) |
| Ranging Frequency | Single shot, 1 Hz |
| Valid Ranging Probability | ≥ 99% |
| Recording Function | Photo & Video Capture |
| File Management | Delete and export media files |
| Storage Capacity | 32 GB Internal Memory |
| Power Supply | 18500 3.7 V 2000 mAh Rechargeable Li-ion Battery (Removable) |
| Battery Life | ≥ 3 hours |
| Operating Temperature | -20 °C to 60 °C |
| IP Rating | IP65 |
| WIFI | Yes |
| Mounting Interface | Multiple 1/4-inch threaded holes for flexible mounting |
| Connectivity Interface | Type-C (supports battery charging and data transmission) |
| Motion Sensors | 3-axis Gyroscope + 3-axis Accelerometer + 3-axis Electronic Compass |
| Housing Material | T6063 aluminum alloy |
| Product Weight | 0.35kg |
| Package Weight | 0.706kg |
| Product Size | 78×44.5×63.8mm |
| Package Size | 163×145×78mm |
| Package Contents | 1 x B215AL 1 x Manual 1 x Battery 1 x Battery charger 1 x USB-C cable 1 x Fixed bracket 1 x Fixing screws 1 x Lens cleaning cloth 1 x Hexagon wrench 1 x Flannel bag |
