Makeblock XY-Plotter Robot Kit V2.0 Drawing Robot Painting Robot Plotting Instrument

Ship to:
United States
Select the desired shipping method
Shipping Company Estimated Delivery Time Shipping Cost
*Please note: the shipping costs are only estimates; the actual shipping price will be shown on the order page.
0 item(s) added
View CartContinue Shopping

Highlights

  • Aluminum extrusion parts stronger than XY-Plotter 1.0, anodizing surface
  • Dual-way transmission mechanism
  • Improved pen rising mechanism
  • Super easy-use stepper motor driver, A4988
  • Updated main board -- Me Orion(Base on Arduino UNO)
  • Easy-Controlled by mDraw
  • XY Plotter Kit can be assembled as a drawing robot,it moves a pen or other instruments to draw digital artwork on flat surface.On the basis of Makeblock platform, XY Plotter can be developed to a laser engraver or others.
  •

Specification

General
Brand Makeblock
Quantity 1 Piece
Material Anodized aluminum
Specification
Working Area 310mm×390mm
XY Accuracy 0.1mm
Max Working Speed 50mm/s
Power 100-240 V~50/60Hz AC/DC Power adapter, 12V/3.0A
Main Controller Makeblock Orion (Arduino UNO compatible)
Software mDraw
Supported File Types .SVG, .BMP etc.
Dimensions & Weight (Main Product)
Dimension 566×333×70mm
Package Contents
1xRobot Kit

Download:Please visit the link to download the software and assembly instruction: //learn.makeblock.cc/xy2/

Parts List

1 x Beam 0824-16

10 x Shaft Collar 4mm

1 x 6P6C RJ25 cable-35cm

4 x Beam 0824-48

1 x Flexible coupling 4x4mm

2 x 6P6C RJ25 cable-50cm

1 x Beam 0824-80

4 x Linear Motion Shaft D8X496mm

1 x Wall Adapter Power Supply - 12VDC

4 x Beam 0824-96

6 x Linear Motion Slide Unit 8mm

1 x USB A-Male to B-Male Cable

2 x Beam 0824-112

10 x Flange Bearing 4x8x3mm

1 x Base Bracket

2 x Beam 0824-496

1 x HEX Screwdriver 2.5mm

4 x  Me Micro Switch B

1 x Beam 0808-80

1 x Cross Screwdriver 3mm

1 x 9g  micro servo bracket

2 x Beam2424-504

2 x HEX Allen Key 1.5mm

1 x Linear Motion Shaft D4x512mm

2 x Bracket 3x3

1 x Wrench 7mm

1 x Linear Motion Shaft D4x80mm

5 x Plate 3x6

50 x Nut M4

3 x Nut M2

5 x Bracket U1

10 x Countersunk Screw M3x8

3 x Cross recessed pan head screw M2×10

3 x  Belt Connector

26 x Headless Set Screw M3x5

30 x Hexagon socket
button head screws
M4×14

2 x 42BYG Stepper Motor Bracket

16 x Plastic Rivet R4060

28 x Hexagon socket
button head screws
M4×16

1 x K-Power 9g Micro Servo

6 x Plastic Rivet R4100

12 x Hexagon socket
button head screws
M4×22

2 x 42BYG Stepper Motor

20 x Plastic Ring 4x7x2mm

18 x Hexagon socket
button head screws
M4×30

6 x Timing Pulley18T

1 x Me-Baseboard

36 x Hexagon socket
button head screws
M4×8

3 x Open-end Timing Belt (1.3m)

2 x Me Stepper motordriver V1.0

6 x Cuttable Linkage 3

2 x D Shaft 4x56mm

3 x RJ25 Adapter

30 x Nylon cable ties 2*100

1 x Threaded Shaft 4x39mm

2 x 6P6C RJ25 cable-20cm

4 x Rubber band





4 x Foot Pad
