Highlights
- Jaw Size: Φ26mm/1.0”
- Tests AC/DC voltage and current, resistance, frequency, duty cycle
- Work light and display Back light
- Diode check and continuity test
- MAX/MIN and data Hold
- - This meter is a portable professional measuring instrument with LCD and back light easily reading. The 'single-hand operation’ design for the range switch makes measurement simple and easy. Overload protection and low battery indication are provided. It is an ideal multi-function Instrument with scores of practical applications for professional, workshop, school, hobby and home use
- - The meter can perform measurements of AC/DC voltage and current, resistance, frequency, duty, capacitance, as well as continuity and diode test
- - Auto range is available
- - This meter is equipped with reading hold function
- - This meter is equipped with square value measuring function (at AC A and AC V range)
- - This meter is equipped with auto zero function (at DCA range)
- - This meter is equipped with maximum value measuring function
- - This meter is equipped with minimum value measuring function
- - This meter can measure frequency by clamp
- - This meter has function of auto power off
|
Specification |
Range |
Accuracy |
|
DC Voltage |
400mV/4V |
±(0.8% +3) |
|
40V/400V/1000V |
±(1.0% +5) |
|
|
AC Voltage |
4V/40V/400V |
±(0.8% +3) |
|
750V |
±(1.0% +5) |
|
|
DC Current |
40A/400A |
±(2.0% +6) |
|
AC Current |
40A/400A |
±(2.0% +6) |
|
Resistance |
400Ω/4kΩ/40kΩ/400Kω |
±(0.8% +3) |
|
4MΩ/40MΩ |
±(1.2% +3) |
|
|
Capacitance |
400nF/4µF/40µF/400µF/4000µF |
±(4.0% +5) |
|
Frequency (From Clamp) |
0~ 10KHz |
±(1.5% +5) |
|
Frequency (From Plug) |
0~ 10MHz |
±(1.5% +5) |
|
Duty Cycle |
1%~ 99% |
±3.0% |
|
Feature |
||
|
Display |
4000 counts |
|
|
Jaw Opening |
Φ26mm/1.0” |
|
|
Auto Ranging |
√ |
|
|
Auto Power Off |
√ |
|
|
REL |
Relative measurement |
|
|
Diode |
2.7V |
|
|
Continuity Buzzer |
<50Ω |
|
|
MAX/MIN |
√ |
|
|
Data Hold |
√ |
|
|
Low Battery Display |
√ |
|
|
Display Backlight |
√ |
|
|
Front Light |
√ |
|
|
General |
||
|
Power Supply |
3×1.5V A AA Batteries |
|
|
Product Size |
208mm×78mm×35mm/ 8.2”×3.1”×1.4” |
|
|
Product Weight |
340g/0.7lb |
|
|
Category |
CE ETL CAT.III 600V |
|
What's in the box?
- 1 * Digital Multimeter
- 2 * Test Leads
- 1 * Instruction Manual
