Highlights
Up to 0.1 mm Precision & IMU Stabilization
Create accurate 3D models of large objects every time with RANGE 2's reliable single-frame precision of up to 0.1 mm. IMU stabilization and smart algorithms help you avoid faulty frames from unsteady hands and provide smoother frame stitching.
Single Capture Area 860 x 1380mm @ 1300mm
Swiftly 3D scan automobiles, large machinery or components, furniture, and people with RANGE 2's 60% bigger single capture area of 860 x 1380 mm at 1300 mm and scanning distance of 400 mm to 1300 mm.
Impressive RGB Camera & Flash LED
Make color-accurate 3D models with RANGE 2's upgraded RGB camera and new Flash LED lighting system, ensuring evenly lit objects for balanced color capture.
Up to 16fps High-Speed Scanning
Save time and enhance workflow productivity with up to 16 fps scanning speeds and a larger capture area, powering the rapid capture of big objects. Do full body and face scans in under 90 seconds. (Note: RANGE 2 uses eye-safe class 1 infrared light.)
Advanced Connectivity
Ditch the PC and take your RANGE 2 mobile by connecting it over fast Wi-Fi 6 to your smartphone for increased maneuverability when scanning large objects. Alternatively, connect over USB Type-C to a laptop for a bigger screen scanning experience.
User-Friendly Operation
The all-new dual LED indicator system displays the RANGE 2's working status, while the tactile buttons allow for easy control of the scanner and the depth camera's exposure. Capture scans and edit models quickly with the free Revo Scan software (frequently updated to add new features). Its intuitive design and one-click model processing feature make it user-friendly for beginners while providing powerful editing functions for advanced users.
Wide Compatibility
Connect your RANGE 2 to Windows, macOS, Android, and iOS devices—output models in OBJ, STL, and PLY formats for compatibility with 3D modeling software and 3D printers.
Specification
| General | Brand: Revopoint Type: 3D Scanner Model: RANGE 2 Color: Black |
| Specification | Technology: Dual-camera Infrared Structured Light Single-frame Precision: Up to 0.1 mm Single-frame Accuracy: Up to 0.3 mm Single Capture Area at Nearest Distance: 220 x 425 mm at 400 mm Single Capture Area at Furthest Distance: 860 x 1380 mm at 1300 mm Working Distance: 400 - 1300 mm Point Distance: Up to 0.1 mm Minimum Scan Volume: 50 × 50 × 50 mm Scanning Speed: Up to 16 fps Position Sensors: 9-axis IMU 3D Light Source: Class 1 Infrared Light Tracking Methods: Feature/Marker PC Requirements (macOS): RAM: ≥8GB CPU (or better): M1 Pro/M1 Max/M1 Ultra, M2/M2 Pro/M2 Max/M2 Ultra, M3/M3 Pro/M3 Max Outdoor Scanning: Yes Color Scanning: Yes Ready to Print 3D Models: Yes Compatible Operating Systems: Window 10/11 (64-bit), Android, iOS, macOS External Controls: Three buttons for Start/Pause, Exposure +, - Infrared Fill Lights: Yes White Flash LEDs: Yes Output File Formats: PLY, OBJ, and STL Wi-Fi: Wi-Fi 6 Connector Type: USB Type-C Special Object Scanning: Use scanning spray for transparent, dark, or highly reflective objects. PC Requirements (Windows): RAM: ≥16GB CPU (or better): i5 12th/13th/14th, i7 12th/13th/14th, i9 all series |
| Weight & Size | Product Weight: 0.253kg Package Weight: 2kg Package Size(L x W x H): 28.5x24x11cm |
| Package Contents | 1 x 3D Scanner 1 x Tripod 1 x Phone Holder 1 x USB Type-A to C Cable 1 x 2-in-1 Mobile Cable 1 x USB Type-C Adapter 1 x Carrying Case 1 x Magic Mat 1 x Power Bank Handle 1 x Markers 1 x Quick Release Plate 1 x Screwdriver |
Videos
Customer Photos
Customer Videos
Customer Reviews
Questions & Answers
FAQ
What are the differences between RANGE 2, POP 3, MINI, and INSPIRE?
Scanning Scenarios. The RANGE 2 is designed for professionals who want to scan large objects such as furniture, people, and vehicles, creating vivid color models. The POP 3 is designed for professionals who want to scan medium-sized objects, such as engine parts or vases. The MINI is designed for professionals who want to scan smaller objects such as jewelry, miniature figurines, or hardware components, providing precise detail-capturing capabilities. The INSPIRE is for hobbyists, 3D printing enthusiasts, and makers who want to scan medium-sized objects.
What’s special about RANGE 2’s IMU?
RANGE 2’s IMU is a 9-axis IMU with a gyroscope, accelerometer, and magnetometer that all work together to help RANGE 2 understand its location as you move the scanner around an object. This, in turn, helps RANGE 2 provide smoother frame stitching and eliminate any faulty frames captured caused by shaking or moving too fast.
What is a Magic Mat?
Magic Mat is an 80 cm x 60 cm black mat with highly reflective marker points across its surface that is designed to make scanning featureless objects much easier by removing the need to place marker points on the item.
How do I recalibrate the RANGE 2’s IMU?
In Revo Scan 5’s Home Screen, click the settings icon next to RANGE 2’s name. Then click on the “Start Calibration” button to start the process. Follow the on-screen instructions to recalibrate your RANGE 2.
Do you need a powerful computer to use the RANGE 2?
No, the RANGE 2’s algorithms and internal chip do most of the processing.
Minimum specs: Intel i5, 8GB RAM.
Recommended specs: Intel i7, 16GB RAM or better.
No discrete GPU like an Nvidia or AMD graphics card is needed to use RANGE 2.
What technology does the RANGE 2 use?
RANGE 2 uses class 1 infrared structured light, dual depth cameras, and advanced algorithms to output detailed 3D models.
Can RANGE 2 safely scan humans and animals?
Yes, the RANGE 2 is entirely eye and skin-safe as it uses class 1 infrared light.
Does RANGE 2 have 3D scanning software?
Yes, the RANGE 2 comes with Revo Scan for free. It is compatible with iOS, macOS, Android, and Windows devices. In Revo Scan, you can perform scans and post-processing.
What formats can Revo Scan export?
Revo Scan can export your models in PLY, OBJ, and STL for compatibility with most 3D modeling, slicer, and CAD software.
Can objects scanned with RANGE 2 be 3D printed?
Yes, the scanned models can be output in STL format, which is compatible with most slicer software.
Is third-party scanning software available for RANGE 2?
No, RANGE 2 is only compatible with the Revo Scan software, which you can download from our website or your device’s app store. However, the models generated by the scan are compatible with nearly all third-party 3D modeling software.
Does RANGE 2 need internet access to work?
No, RANGE 2 does not need to be connected to an internet-capable network to work.
How do I export scanned models on my phone?
You can send the projects on your phone to a PC. Ensure your phone and PC are connected to the same Wi-Fi network. Don’t minimize the app or turn off your phone’s screen during the file transfer, or the transfer will fail.
● Import from Phone via Verification Code
1. Click the Import From Phone button.
2. Open Revo Scan V5.0 or above on your phone and find the project you want to share.
3. Tap the Share icon.
4. Enter the code shown on your PC to your smartphone.
5. Start file transferring.
● Import from Phone via QR Code
1. Click the Import From Phone button.
2. Click the QR Code icon.
3. Open Revo Scan V5.0 or above on your phone, and find the project you want to share.
4. Tap the Share icon.
5. Scan the QR code on your PC.
6. Start file transferring.
What are marker points used for?
Marker points are stuck on or around objects without geometric features, so the RANGE 2 can track what it is scanning. When using marker points, place them in irregular patterns with around 6 ~ 10 cm between the markers across the object you’re scanning, and ensure that there are 5 marker points always in the frame when scanning.
Do more frames scanned mean better 3D scan accuracy?
No, repeated scanning makes your model worse. One scan close to the object will result in the best accuracy.
Are there any objects that the RANGE 2 can’t scan?
Like most 3D scanners, highly reflective, transparent, or dark objects can only be effectively scanned using 3D scanning spray to coat the object’s surface.
Can I use the RANGE 2 outdoors?
Yes, but it won't work well in direct sunlight. The RANGE 2 is not water resistant, so avoid outdoor scanning on rainy days.
What’s the minimum size of an object RANGE 2 can scan?
RANGE 2 has a minimum scan volume of 50 mm x 50 mm x 50 mm.
Can RANGE 2 scan objects smaller than 50 mm x 50 mm x 50 mm?
Yes, but advanced scanning skills and post-processing are needed. Keep in mind that the smaller the object and its details, the less RANGE 2 will be able to detect, as it’s optimized for large object scanning.
