Highlights
Fully Enclosed Class 1 Safety Design
The E1 features a fully enclosed structure that reduces smoke, heat, and noise while providing enhanced safety. Its Class 1 safety-certified enclosure filters up to 99% of laser light and includes a safety lock, emergency stop button, Hall sensor, and automatic laser shutdown when the cover is opened.
Powerful 12W Laser Performance
Equipped with a 12W 455nm diode laser, the E1 delivers precise engraving and efficient cutting. It can cut up to 6mm wood and 5mm black acrylic in one pass, with engraving speeds up to 600mm/s for fast and accurate results.
Dual-Laser Compatibility
The E1 Dual version adds a 3W 1064nm IR laser module, enabling detailed engraving on metals and plastics. Compatible with over 360 materials, it expands creative and professional applications.
Large 400 × 320mm Working Area
With a 400 × 320mm working area and 450 × 350mm material placement area, the E1 handles larger projects with ease and supports materials up to 42mm thick.
High-Precision CoreXY Motion System
The advanced CoreXY structure provides smooth movement, accurate positioning, and faster operation, ensuring high-quality engraving and cutting performance.
Plug-and-Play Operation
Designed with an all-in-one structure, the E1 requires minimal setup. It supports the free Sculpfun Space software, making it easy for beginners and professionals to start creating.
Built-In Camera & Expandable Accessories
A built-in camera, pre-installed honeycomb panel, and air assist system improve workflow and accuracy. The E1 also supports optional accessories such as a rotary attachment, riser base, and smoke purifier for expanded functionality.
Specification
| Brand | SCULPFUN |
| Type | Laser Engraver |
| Model | E1 Dual |
| Color | White-Green |
| Laser Power | 12W 455nm Diode Laser + 3W 1064nm IR Laser |
| Connection | USB / Wi-Fi (App Only) |
| Operating Voltage | 24V |
| Operating Current | 4A |
| Working Area | 400 × 320mm |
| Material Placement Area | 450 × 350mm |
| Maximum Processing Thickness (With Honeycomb Panel) | 30mm |
| Maximum Processing Thickness (Without Honeycomb Panel) | 42mm |
| Diode Laser Spot Size | 0.04 × 0.06mm |
| Diode Laser Engraving Materials | Wood, Bamboo, Cardboard, Plastics, Leather, PCB Boards, Anodized Aluminum, 304 Stainless Steel, Ceramics, Dark-Colored Stone |
| Diode Laser Cutting Materials | Wood Sheets, Acrylic Sheets, Cardboard, Non-Woven Fabric, Bamboo Sheets, Certain Plastic Sheets |
| IR Laser Spot Size | 0.03 × 0.03mm |
| IR Laser Engraving Materials | Metals, Plastics, Wood, Leather, Acrylic, Stone, Ceramics, Glass, Paper (300+ Materials) |
| Product Weight | 12.05kg |
| Package Weight | 18.35kg |
| Product Size (L x W x H) | 590×500×205mm |
| Package Size (L x W x H) | 675×585×285mm |
| Package Contents | 1 x Machine 1 x User Manual 1 x 455nm Laser Module (Pre-installed) 1 x 1064nm IR Laser Module 1 x Exhaust Hose 1 x Flange 1 x Hose Clamp 1 x Air Pump 1 x Air Hose 1 x Safety Goggles 1 x 24V/4A Power Adapter 1 x Honeycomb Panel (Pre-installed) 1 x Tool Kit 1 x USB Safety Key 1 x Cable Set 2 x Camera Calibration Papers 1 x Laser Maintenance Kit 5 x 3mm Basswood Sheets |
