Highlights
10 Years Lifetime & 1/3 Lightweight
LANPWR LiFePO4 battery provides 4000+ cycles, which is more than 10 times Lead Acid with 200-500 cycles, helping to minimize replacement cost and reduce the total cost of ownership. weighs only 1/3 the weight of lead-acid batteries, which makes it an easy choice for RVs, Marine, and Off-Grid Applications when mounting or mobility is in consideration.
Automotive Grade Lithium Battery & Eco-friendly
24V 100Ah LANPWR lithium iron phosphate batteries have exceptional quality since they are manufactured by Automotive Grade LiFePO4 Cells with higher energy density, more stable performance & greater power. With no acid in the battery, you're able to safely mount it in any position. LiFePO4 batteries can be recycled and do not produce elements that are harmful to the environment, but lead-acid batteries pollute the environment.
Capacity Expansion
LANPWR LiFePO4 battery can be connected in parallel and in series for larger capacity and voltage. Max connection in series: Up to 2 identical batteries for up to 51.2V connecting in series. Connection in parallels: it can connect multiple batteries, suggesting no more than 4pcs in parallel. Allow to be extended up to 2 in series and 4 in parallel (Max 2S4P) to get more capacity (Max 400Ah) and higher voltage (24V, 48V). When the batteries are used in parallel or series, the battery voltage and capacity must be the same and purchased in near time (within 3 months).
Built-in 100A BMS
LANPWR LiFePO4 battery has built-in 100A BMS (Battery Management System) to protect it from overcharge, over-discharge, over-current, and short circuits with an excellent self-discharge rate. Built-in high-temp cut-off prevents charging over 122°F(50°C). Without memory effect, no matter what state the battery is in, it can be used as soon as it is charged. LANPWR LiFePO4 battery is IP65 level.
Specification
| General | Brand: LANPWR Type: LiFePO4 Battery Model: LFP24-100 Color: Black |
| Specification | Nominal Voltage: 25.6V Nominal Capacity: 100Ah (C5, 25 Celsius) Energy: 2560Wh Internal Resistance: ≤60mΩ Cycle Life: ≥4000 cycles @0.2C 100% DOD Months Self Discharge: ＜3% Efficiency of Charge: 100% @ 0.2C Efficiency of Discharge: 96-99%@0.5C Charge Mode: 29.2 ±0.2V Charge cut-off voltage: 0.2C charge to 29.2V Charge current: 20A Continuous current: 100A Max Pulse current: 300A(＜3s) Discharge cut-off voltage: 20V Storage Temperature: -10 to 40 Celsius (14 to 104 Fahrenheit) Charge Temperature: -5 to 45 Celsius (23 to 113 Fahrenheit) Discharge Temperature: -20 to 60 Celsius (-4 to 140 Fahrenheit) Combination Method: 2S4P Plastic Case: ABS Terminal: M8 |
| Weight & Size | Product Weight: 21kg Package Weight: 22.5kg Product Size(L x W x H): 49x23x22cm Package Size(L x W x H): 57x28x30cm |
| Package Contents | 1 x LiFePO4 Battery 1 x User Manual |
