Highlights
Rockchip RK3229
Rockchip RK3229, a quad-core ARM Cortex-A7 processor teamed with ARM Mali-400MP2 graphics, supports 10/100Mbps Ethernet, HDMI 1.4, and 10-bit H.265 2160p video playback.
DDR3 2GB RAM, eMMC 8GB Flash
It boasts DDR3 2GB RAM, and eMMC 8GB Flash, advantageous in performance, security and reliability, ascribing to the eMMC memory, ultimately delivering a richer end-user experience.
4K Resolution
The latest in a line of broadcast and media resolutions, 4K is due to replace 1080p as the highest-resolution signal available for in-home movies and television. With a minimum resolution of 3,840 pixels wide and 2,160 pixels high, making it the equivalent to two 1080p screens in height and two in length.
802.11 b/g/n
Supports 802.11 b/g/n wireless standard, among which 802.11b has a maximum bandwidth of 11 Mbps, 802.11g 54 Mbps and 802.11n 150 Mbp
Specification
| General |
Model:M8S PRO |
| Software | OS:Android 6.0 XBMC/KODI:17.2 HDCP 2.2/1.4 Support language:Chinese, English, Germany, Japanese, Korea etc. multilateral languages |
| Hardware | CPU:RK3229, 28nm Quad core Cortex A7, High cost performance 4K OTT Box solution GPU:ARM Mali-400 GPU Memory:2GB DDRIII Flash:8GB EMMC |
| Communication | WiFi:802.11 b/g/n, Wired network:Ethernet GMAC 10/100M Ethernet controller |
| Media | 3D:Hardward 3D graphics acceleration Video decoding:4K VP9 Video decoder, 4K 10-bits H.265/H.264 video decoder 1080P other video decoders (VC-1, MPEG-1/2/4, VP6/8) Support conversion from BT.2020 to Rec.709/Rec.601 Video post processor: de-interlace Support H.263/H.264 2160P@ 24fps Support VC-1 ,MPEG - 1 1080p @ 60fps Support MPEG- 2 2160P @ 24fps Support MPEG-4 1080P @ 60fps Support AVS 1080p @ 60fps Support MVC 2160P @ 24fps Support WMV,3GP,MKV,ASF,3G2M4V,MJPEG,RV8,RV9,RV10 1080P@60fps Support HEVC decoder Support Main/Main10 HEVC/H.265 decoder, 4K @ 60FPS Support 4096x2304 resolution Support HDMI 720P-2160P FUII 3D HD( 2160P, 3840 * 2160 ), 4K+2 K Support flash11.1 Video Decoder format:H.264,H.265,VP8,MVC(1080P) Video format:Supports DIVD/DIVX/REAL8 / 9 / 10, RV, RM, RMVB, PMP, FLV, MP4, M4V, VOB, VP6, VP8 2160P @ 24fps Audio format:Supports MP1, MP2, MP3, WMA, OGG, AAC, M4A , FLAC, APE, AMR, RA, WAV, etc Picture format:Supports JPG, JPEG, BMP, GIF, PNG, JFIF etc Resolution 8192x8192 HDD file system:FAT16 / FAT32 / NTFS Support Subtitle:SRT, SMI, SUB, SSA, IDX+USB |
| Appliactions | Online:Browse all video websites, support Netflix, Hulu, Flixster, youtube etc Apps:Apps download freely form android market, amazon appstore etc Medium:Local Media playback, support HDD, U disck ,SD card Talk online:Support SKYPE video call, MSN, facebook, twitter, QQ etc Others:Support WiFi hotpiont, could be as a wireless router Support DLNA, Google TV Remote, LAN, 3D Moive, Email, office suit etc |
| Interface | 1*HDMI 1.4b with CEC; Built-in HDMI 1.4b transmitter including both controller and PHY with CEC and HDCP, 4K @ 60FPS max resolution output 1*Mirco SD Card (TF); TF cards (up to 32GB) 4*USB HOST; 2High speed USB 2.0,support USB DISK and USB HDD 1*SPDIF; SPDIF output 1*RJ45; Ethernet:10/100M, standard RJ-45 1*Digital display tube; Digital display tube 1*Power input; 5V/2A |
| Power | DC 5V/2A |
| Dimensions & Weight | 11.5*11.5*2.7cm/4.5*4.5*1inches ;143g/5.05oz |
| Package Contents | TV Box Power adapter(A right power adapter will be sent according to your country) HDMI cable IR remote control User Manual |
