Highlights
- - Diode test
- - Continuity test
- - Auto power off
- - Resettable fuse inside
- - Data hold
- - Back light
Specification
Conform to the IEC1010-1 standard CAT III 600V and CAT II 1000V
- Sound & light warning for the incorrect inserting the input plug
- SMT application
- Display: 19999 counts
- DC voltage: 200mV±0.05%, 2/20/200V±0.1%, 1000V±0.15%
- AC voltage: 2V±0.5%, 20/200V±0.6%, 750V±0.8%
- DC current: 2mA±0.5%, 200mA±0.8%, 10A±2.0%
- AC current: 2mA±0.8%, 200mA±1.2%, 10A±2.5%
- Resistance: 200Ω±0.5%, 2k/20k/200k/2MΩ±0.3%, 20MΩ±0.5%, 200MΩ±5%
- Capacitance: 20nF/200n/2μ/20μ/200μF±4.0%
- Frequency: 20kHz±1.5%
- hFE: 1~1000
- Power: 6F22(9V)x1
- Size: 195mm x 92mm x 55mm
- Weight: Approx. 380g(including battery)
What's in the box?
- 1 x MS8265 Multimeter
- 1 x Manual
- 1 x set Test Leads
