Highlights
Shimano 11 speed Transmission System
Front and rear hydraulic disc brakes.
ADO G-DRIVE dual mode controller. Dual mode switched freely.
Wire-controlled front fork Shock-absorption
S830 central smart LCD display, clearly under the sunshine
Specification
| General | Brand: ADO Type: 27.5*1.95 Inches Model: D30 Color: Grey/Silver |
| Vehicle Performance | Dimensions L×W×H: 1800*640*1100mm Package Size: 1480x260x780 mm Operating Temperature: -10~40°C Storage Temperature: -20~50°C Net Weight: 22 Kg Gross Weight: 29.5 Kg IP Rating: IPX5 Max. Speed: 25km/h Transmission: Shimano 11 speed Gear ratio: (40-11):44 Electric range: / Assisting range: <90km Shock-absorption: Wire-controlled shock absorber front fork Brake: Front & Rear Hydraulic disc brake Payload: ≤120kg Charging time: 6-7 hours |
| Head of Bicycle |
Material: Aluminum alloy |
| Front Wheel | Drivenmethod: / Material: Aluminum alloy Hub type: spokes hub Size: 27.5 Inch Tire: Rubber pneumatic tire (American gas nozzle) Brake: Hydraulic disc brake |
| Rear Wheel |
Drivenmethod: Motor drive wheel Material: Aluminum alloy Hub type: spokes hub Size: 27.5 Inches Tire: Rubber pneumatic tire (American gas nozzle) Brake: Hydraulic disc brake |
| Main Frame |
Material: Aluminum alloy Type: Fixed tripod Parking: Middle kickStand Battery location: Built into the down tube Reflect Sticker: The taillights are under the saddle, and on the front/rear spokes Max Steering Angle: 90°(each side) Rear Light: Electric taillight Air pump: Accessory Foot Pad Material: Aluminum alloy Foot Pad Type: Fixed Carrying handle: No |
| Light auxiliary settings | Front white light + white reflector: YES Rear red light + red reflector: YES Two yellow reflectors before and after the pedal: YES Two yellow reflectors on the spoke: YES |
| Battery | Material: Lithium battery Type of batteries: Removable portable charging Battery number: 40PCS Rated Voltage: 36V Charge cut-off voltage: 42V Rated Capacity: 36V10.4 AH Charging Temperature: 0~40°C Battery Management System: Over-heating, Short circuit, Over- current, Over-charge protection |
| Charger | Input Voltage: 100~240V, 50/60Hz Output Voltage: 42V DC Output Current: 2A Output Power: 84W |
| Motor | Brand: \ Motor Type: Hall Brushless Gear DC Motor Rated Voltage: 36V Rated Power: CE Version, 250W Max. Power: \ Torque: 42N.m Rated speed: 380 r/min |
| System Control | Display Type: S830 central smart LCD display, Clearly under the sunshine Display Contents: Speed, mileage, Gear, glitch Electronic booster starting point: 6 KM start Under voltage protection: 31±2V Over current protection: 15±2A |
Customer Photos
Customer Videos
Customer Reviews
Questions & Answers
FAQ
1. Please wear a helmet including other safety protective gear all the time while riding. Ride safely and obey your local laws and regulations.
2. If you want to store the bicycle/scooter for an extended period, make sure the battery is charged well above 50%. Be mindful that the battery is stored at a dry and safe area.
3. Please do not charge the battery indoors.
