EASUN POWER 3600W Solar Inverter, MPPT 100A Solar Charger, 24V DC, 230V AC Off Grid Inverter, Built-in WiFi

General

Brand: EASUN POWER
Type: Solar Inverter
Model: BA-ISOLAR-SMG-II-3.6KW-WIFI
Color: White

Specification

Capacity: 3.6KVA/3.6KW
Parallel Capability: No

Input
Nominal Voltage: 230V AC
Acceptable Voltage Range: 170-280V AC (For personal Computer); 90-280V AC (For Home Appliances)
Frequency: 50/60Hz (Auto sensing)

Output
Nominal Voltage: 220/230V AC ± 5%
Surge Power: 7000VA
Frequency: 50/60Hz
Wave Form: Pure sine wave
Transfer Time: 10Ms (For personal Computer); 20Ms (For Home Appliances)
Peak Efficiency (PV to INV): 96%
Peak Efficiency (Battery to INV): 93%
Overload Protection: 5s@>=150% load; 10s@110%-150% load
Crest Factor: 3:1
Admissible Power Factor: 0.6-1 (inductive or capacitive)

Battery
Battery Voltage: 24V DC
Floating Charge Voltage: 27V DC
Over Charge Protection: 33V DC
Charging Method: CC/CV

Solar Charger & AC Charger
Solar Charger Type: MPPT
Max.PV Array Power: 4000W
Max.PV Array Open Circuit Voltage: 500V DC
PV Array MPPT Voltage Range: 120V DC - 450V DC
Max. Solar lnput Current: 15A
Max. Solar Charge Current: 100A
Max. AC Charge Current: 60A
Max. Charge Current: 100A
Communication Interface: WIFI/Dry-contact

Environment
Operating Temperature Range: -10 to 50 Celsius
Storage Temperature: -15 to 60 Celsius
Humidity: 5% to 95% Relative Humidity (Non-condensing)

Weight & Size

Product Weight: 9kg
Package Weight: 9kg
Product Size(L x W x H): 48.2x29.x11.3cm
Package Size(L x W x H): 56.5x38x19cm

Package Contents

1 x Off-grid Solar Power Inverter
1 x Communication Cable
1 x User Manual
