Highlights
- Support Onvif Protocol.
- Support 18S super Protocol.
- Support P2P cloud service, remote viewing.
- Support megapixek HD network video preview, storage and playback.
- Support search, playback and backup by event.
- Build in 1 SATA Interface and support 2.5 inch HDD.
- Offer CMS for free.
Specification
| Model Number | ESCAM MINI NVR K508 | |
| Operating System | Embedded LINUX operating system | |
| Image Code Control | Image code quality adjustable, variable bitstream and constant bitstream optional | |
| Dual Stream | Each channel can set main stream and sub stream | |
| Video Standard | 1080P(1920×1080)30fps/960P/(1280×960)/720P(1280×720)30fps | |
| Monitoring Image Quality | 1080P(1920×1080) / 960P/(1280×960)/720P(1280×720) | |
| Image Motion Detection | Each screen can set mutiple detection areas and set 6-level sensitivity(IPC Support) | |
| Recording Playback Quality | 1/4/8ch playback simultaneously | |
| Region Cover | Every channel can set 4 cover regions(IPC Support) | |
| Recording Mode | Support manual , auto, dynamic detection, alarm trigger record mode(Partly needs IPC Support) | |
| Backup Way | Support U disk, USB mobile HDD, USB DVD-RW. network storage and backup | |
| Operation Way | Mouse | |
| Local Login | Username and password | |
| Recording Storage | Local HDD, network | |
| External Ports | Video Input | 8×(1280*720)+sub[640*360]+1Ref.+4Play 8CH 1.0MP IP Camera |
| 8×(1280*960)+sub[640*480]+4Ref.+1Play 8CH 1.3MP IP Camera | ||
| 8×(1280*1080)+sub[640*480]+2Ref.+1Play 8CH 2.0MP IP Camera | ||
| 8×(1920*1080)+sub[720*576]+1Ref.+1Play 8CH 2.0MP IP Camera | ||
| Audio Input | 8ch network audio input | |
| Video Output | 1ch VGA+1ch HDMI | |
| Network Port | 1 RJ45,10M/100M self-adaptive LAN port | |
| USB Port | 2 USB 2.0 ports | |
| HDD | HDD Port | 1 2.5” SATA HDD Port + 1 E-SATA HDD Port |
| MAX Capacity | Each port supports MAX 4TB HDD | |
| Mobile Surveillance | Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) smart phone | |
| Power Supply | 5V2A | |
| Power Consumption | ≤10W(without HDD) | |
| Working Temperature | -10ºC~+55ºC | |
| Working Humidity | 10%-90% | |
| Dimension | Equipment:162mm×162mm×35mm, Packing: 210mm×210mm×65mm | |
| Weight(without HDD) | N.W.:280g;With packing:700g | |
| Installation Way | Desktop Installation | |
What's in the box?
- 1 x ESCAM K508 8 Channel NVR
- 1 x Power Supply (EU / US / AU / UK Plug for Optional)
- 1 x English User Manual
