Highlights
Android 6.0 + OpenELEC + Ubuntu + Buildroot Multi-OS
Pre-installed Android,you can also install Ubuntu, OpenELEC, Buidroot OS. Bring you surprise of using experience
Amlogic S905X Quad-core CPU
Rapid and stable which can give you high-speed feedback and smooth response
Bluetooth 4.2 Connectivity
Easy pairing with most Bluetooth-enabled devices
2GB DDR3+8GB EMMC-V5.0
It boasts DDR3 2GB RAM, and eMMC 8GB Flash, advantageous in performance, security and reliability, ascribing to the eMMC memory,ultimately delivering a richer end-user experience.
2.4GHz / 5.0GHz WiFi
Connecting effortlessly in a world without wires
Multible Use Case
You can turn Khadas VIM Development Board into SBC, Clusters, Digital Signage, Robotics, IoT, TV Box, Smart Karaoke Media Box
Tiny Form Factor
Thin with dimensions of credit card
| General |
Brand: Khadas
Model: VIM
Type: TV Box
GPU: Mali-450
System: Android 6.0,Buildroot,OpenELEC,Ubuntu
CPU: Amlogic S905X
Core: Quad Core
RAM: 2GB
RAM Type: DDR3
ROM: 8GB
Max. Extended Capacity: 64GB
Maximum External Hard Drives Capacity: 64GB
Color: Transparent
|
| Media Supported |
Decoder Format: H.263,H.264,H.265,HD MPEG4
Video format: AVC,AVI,DAT,H.264,H.265,MKV,MPEG-4,REAL MEDIA,VP9
Audio format: AAC,FLAC,MP3,OGG,RM,WMA
Photo Format: BMP,GIF,JPEG,JPG,TIFF
Support 5.1 Surround Sound Output: Yes
|
| Product Details |
5G WiFi: Yes
WIFI: 802.11b/g/n
Bluetooth: Support
Power Supply: Charge Adapter,USB Port
Interface: HDMI,LAN,TF card,Type-C,USB2.0
Language: Multi-language
DVD Support: No
HDMI Version: 2.0
Other Functions: DLNA,Miracast
External Subtitle Supported: Yes
HDMI Function: CEC
Power Comsumption: 1.4W
RJ45 Port Speed: 100Mbps |
| Firmware Information |
System Bit: 64Bit
WiFi Chip: AP6212
KODI Pre-installed: Yes
KODI Version: V17.0 Krypton
|
| Power Requirement |
Power Type: External Power Adapter Mode
|
| Battery Information |
Remote Controller Battery: No
|
| Dimension & Weight |
Product weight: 0.070 kg
Package weight: 0.165 kg
Product size (L x W x H): 9.20 x 6.60 x 2.20 cm / 3.62 x 2.6 x 0.87 inches
Package size (L x W x H): 10.20 x 7.60 x 3.20 cm / 4.02 x 2.99 x 1.26 inches
|
| Package Contents |
Package Contents: 1 x Khadas VIM TV Box, 1 x USB-C Cable
|
