VGA Audio/Video to HDMI Converter L/R PC DVD AV HDTV(Up/Down scaler)

Introductions:

• This kind of the Converter is a VGA video converter. It converts VGA input into HDMI to allow PC users to show their image not only on the PC monitor, but could also on TV, to have a large display. The conversion is along with the R/L audio.

• Item offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and Projector factory, noise space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.


Highlight:

• The series of the HDMI Amplifier Switcher have many features that enable them to perform in a superior manner.Among those features you will find:

• 1 Easy to Use: Install in seconds, no need of setting.

• 2 Conversion: It could convert PC VGA video and R/L audio into completeHDMI.

• 3 Extra VGA and R/L audio outputs: the outputs could be connected back to PC monitor and speakers.

• 4 Manual adjusting button: used for position the image precisely under some extreme condition.

• 5 HDCP pass-through

Specifications:

• Signal Inputs/Output
• Input Video Signal.................................0.5-1.0 volts p-p
• Input DDC Signal..................................5 volts p-p (TTL)
• Maximum Single Link Range....................1600X1200, 1080P
• Output Video ..........................................HDMI + HDCP1.0/1.1
• VGA......................................................640x480 60Hz 72Hz 75Hz
• 800x600 60Hz 72Hz 75Hz
• 1024x768 60Hz 70Hz 75Hz
• 1280x1024 60Hz
• 1600x1200 60Hz
• DTV/HDTV.............................................480i/576i/480p/576p/720p/1080i/1080P
• Digital Signal I/O....................................HDMI Compliance HDMI 1.3
• Operating Frequency...............................Up to165Mhz
• Video Amplifier Bandwidth.......................1.65Gpbs/165MHz
• Resolutions(HDTV) Interlaced(50&60Hz)..................480i,576i,1080i
• Progressive(50&60Hz)...........................................480p,576p,720p,1080p
• Mechanical Size(W-H-D).............................89mmW x 29mmH x 68mmD
• Weight(Net)........................................0.68kgs
• Warranty Limited Warranty..........................1 Year
• Parts and Labor Environmental Operating Temperature............0 to +70
• Operating Humidity.................................10% to 85 % RH (no condensation)
• Storage Temperature..............................-10 to +80
• Storage Humidity...................................5% to 95 % RH (no condensation)
• Power Requirement External Power Supply............5V

Detail:

What's in the box?

• 1xVGA to HDMI Converter
• 1xAC Adapter
• 1xUser Manual
