Highlights
- The chip is ARM chip whose speed is faster and the communication speed is doubled than Wi-Fi OBD (CLK DEVICE)
- The shape looks elegant and refined the design is similar to the style
- Compared with the CLK DEVICE this new device is more exquisite w/o cable
- It has the function of auto power off energy-saving and protection
- When the main chip is detected not in communication for an hour then the device will be off automaticly and get into energy saving state which only consumes 3mA electric
- The real J1939 and the stable J1979 protocol provide customers w/ second development
- Supports all Wi-Fi systems (Android PC Wince Iphone Ipad)
Specification
|
Brand |
Vgate |
|
Color |
White |
|
Material |
PVC |
|
Function |
Clear trouble codes |
|
Wireless Bluetooth |
No |
|
Diagnose Interface |
16pin |
|
Language Supported |
English |
|
Application Supported |
Smartphone laptops |
|
Smartphone Brand Supported |
All w/ Wi-Fi system |
|
Software Platform Supported |
Android PC WINCE Iphone Ipad |
|
Protocols Supported |
ISO15765-4 (CAN) ISO14230-4 (KWP2000) ISO9141-2 J1850 VPW J1850 PWM |
|
Output Protocol |
Standard Wi-Fi |
|
Baud Rate |
38400 |
|
Indicator LEDs |
Blue |
|
Compatible Make |
Cars support protocol |
|
Operating Voltage |
12 V |
|
Working Current |
250 mA |
|
Other Features |
Distributes address freely which is not same as the traditional ADHOC providing a clear and simple connection for customer; Technical Specifications: SSID: V-LinK; IP: 192.168.0.10; Subnet: 255.255.255.0; Port: 35000; Range: 50 ft (Line of sight); Antenna: Internal; Power Consumption: 0.75 Watts (With Power Switch); Wi-Fi Standard: 802.11a/b/g; Operating Temperature: -15~100'C; Plastic: Automotive Grade; Physical Dimensions: 2.75 x 1.25 x 1.2 inches; Functions: Read diagnostic trouble codes both generic and manufacturer-specific and display their meaning (over 3000 generic code definitions in the database); Clear trouble codes and turn off the MIL ("Check Engine" light); Display current sensor data including Engine RPM Calculated Load Value Coolant Temperature Fuel System Status Vehicle Speed Short Term Fuel Trim Long Term Fuel Trim Intake Manifold Pressure Timing Advance Intake Air Temperature Air Flow Rate Absolute Throttle Position Oxygen sensor voltages/associated short term fuel trims Fuel System status Fuel Pressure |
| Dimensions | 2.01 in x 1.81 in x 0.91 in (5.1 cm x 4.6 cm x 2.3 cm) |
| Weight | 1.09 oz (31 g) |
