i6 6inch LED HUD Head Up Display OBDII Over Speed Warning Tire Indicator With Compass

Highlights

• Detecting car’s OBDII interface automatically and all car with OBD II or EUOBD are OK, plug and play;
• Car speed, engine speed, water temperature, voltage / throttle position / Ignition angle / one-hundred-kilometer acceleration time, instant fuel consumption, average fuel consumption, mileage, fuel shortage reminding, engine faulty, shift reminding, etc. are displayed.
• Normal display mode, high-speed display mode and automatic display mode are set by yourself;
• Kilometers and miles are free to switch, which greatly facilitates the dashboard of British Standard;
• 6 inches display area, easy to read
• Switch on and off automatically, HUD start when car starting , HUD shutdown when the engine is turning off to protect the car battery effectively; at the same time, you can switch on and off HUD by Manually Shutdown to protect the battery safety.
• Single-stage and four-stage overspeed alarm for driving safely.
• Engine speed alarming so that you can shift timely to save fuel, also has a special significance for the novice;
• Automatic and manual brightness adjustment mode, no dazzling;
• Compass (this function is optional), the precise position, car does not get lost; Accurately determining the position and not get lost

Specification

Size: 156 x 93 x 15mm

Weight: 130g

Installation Instructions:

1 Make sure if your car complies with OBD II (or EU OBD) interface standard;

2 Open up the engine hood and look for the OBDII sticker. If there is a sticker of “OBDII

CERTIFIED, then you can use our HUD. You can also check if your car have a

diagnostic Interface(the vast majority of cars made in china after 2006 have the diagnostic

Interface).

3 If your car has a diagnostic Interface of 16PINthen plug the OBDII cable with the

diagnostic Interface of 16PIN.

4 Put the non-slip mat on the relatively flat position of the car console. Then you put HUD on

the non-slip mat and adjust HUD.

5 Reflective film can be attached to the front windshield above HUD so that you can read the

parameters form the reflective film.

Remarks: tips of sticking the reflective film

A. Firstly spray some water on the position of sticking the reflective film;

B. Remove the protective layer of the film, then attach to the corresponding position;

C. Adjust the location, then use a small scraper or a smooth object to scrape the surface of the film;

D. After a few minutes, the moisture will evaporate, then gently wipe off the water droplets and dust.

6 Power-on test

You switch on HUD and HUD shows the current car voltage. Then HUD searches the car

computer system. If HUD displays data, such as car speed, engine speed etc, it indicates that the

product has been installed successfully.

HUD setting method

The value HUD displays is the value of car inside computer system. Since the value that the

car dashboard displays is a little bit different from the value of car inside computer system , so you

can enter the setup mode to fine-tune the display value of HUD to achieve exactly the same

values that the dashboard displays.

1 Specific setup

Firstly, you need to connect HUD to the car, then press the OK button for 3 seconds to enter

the setting mode. You can press the OK button once, the value of Menu 3 increases by 1. The

value of Menu 1 increases or decreases by 1 by dialing up or down the dial switch once, which

achieves the same values of HUD as the value the car dashboard displays

1) Enter the setup interface, each parameter adjustment value show as follows Table 1:

What's in the box?

• 1 x Host machine of HUD
• 1 x Reflecting film
• 1 x OBD2 Connecting line
• 1 x Instruction Manual
• 1 x Non-slip mat
