Highlights
Android 5.1 OS
Android 5.1 OS, rapid and stable, with a redesigned user interface built around a design language known as "Material design", avails the access to over 800,000 apps including Facebook, Youtube, Picasa and more.
RK3368
The RK3368 is an ARM Cortex-A53 processor with PowerVR G6110 graphics to support smooth high-resolution (3840x2160) display and mainstream games. It has everything an Android TV Box should have in terms of hardware. Most importantly, the processor boast a maximum clock speed of 1.5 GHz.
DDR3 2GB RAM, eMMC 16GB Flash
It boasts DDR3 2GB RAM, and eMMC 16GB Flash, advantageous in performance, security and reliability, ascribing to the eMMC memory, ultimately delivering a richer end-user experience.
IEEE 802.11ac
IEEE 802.11ac, one of the wireless networking standards in 802.11 family, is developed in the IEEE Standards Association process for the purpose of high-throughput wireless local area networks (WLANs) on the 5 GHz band.
Gigabit LAN
Gigabit LAN provides a data rate of 1 billion bits per second.
Specification
| General | |
|---|---|
| Brand | N/A |
| Model | i68 |
| Color | Black |
| Material | Plastic |
| System | |
| Operating System | Google Android 5.1 |
| CPU | Rockchip R3368 Octa Core up to 1.6GHz (Cortex-A53 64bit) |
| GPU | SGX6110; support 4K*2K H.265/H.264 |
| RAM | DDR3 2G |
| ROM | Onboard eMMC Flash 16GB |
| Extended Storage | Micro SD Card (Maximum support 32GB) |
| Communication | |
| Wifi Connectivity |
IEEE 802.11ac/b/g/n/mimo, WiFi compliant; 4.900 GHz ~ 5.845 GHz (5.0 GHz ISM Band) AP6335 |
| Ethernet | 100/1000M LAN |
| Bluetooth | BT 4.0 |
| Media | |
| Video/Picture Supported | HEVC/H.265 decoder by 4k@60FPS Support up to 4096x2304 resolution Support up to 100Mbps bit rate Embedded memory management unit(MMU) Stream error detector (28 IDs) Internal 128k cache for bandwidth reduction Multi-clock domains and auto clock-gating design for power saving Real-time video decoder of MPEG-1, MPEG-2, MPEG-4, H.263, H.264, AVS, VC-1, RV, VP6/VP8, Sorenson Spark, MVC Error detection and concealment support for all video formats Output data format is YUV420 semi-planar, and YUV400(monochrome) is also supported for H.264 H.264 up to HP level 5.2:4Kx2K@30fps (4096x2304) MPEG-4 up to ASP level 5:1080p@60fps (1920x1088) MPEG-2 up to MP:2160p@30fps (3840x2160) MPEG-1 up to MP:1080p@60fps (1920x1088) H.263:576p@60fps (720x576) Sorenson Spark:1080p@60fps (1920x1088) VC-1 up to AP level 3:1080p@30fps (1920x1088) RV8/RV9/RV10:1080p@60fps (1920x1088) VP6/VP8:2160p@24fps (3840x2160) AVS:1080p@60fps (1920x1088) MVC:2160p@30fps (3840x2160) For AVS, 4:4:4 sampling not supported For H.264, image cropping not supported For MPEG-4, GMC(global motion compensation) not supported For VC-1, upscaling and range mapping are supported in image post-processor For MPEG-4 SP/H.263/Sorenson spark, using a modified H.264 in-loop filter to implement deblocking filter in post-processor unit |
| Resolution | 4K*2K |
| Interfaces | |
| HDMI Port | HDMI 2.0 |
| Other Interfaces | 3* Standard USB; 1* micro USB with OTG; 1*DC in Jack; 1*H DMI IN Port; 1*S/SPDIF (2CH, 5.1CH); 1*RJ45; 1* SD card |
| Power | Adapter 5V 2A |
| IR Sensor | 1*IR |
| Power LED | 1* power LED with two - color |
| Button | 1*Power Button 1*Update Button(via one pin hole) |
| Other Features | |
| Other Function |
Antenna: Built-in antenna for WIFI |
| Work Environment | 5- 35 Degrees, 30%--90% Humidity |
| Storage Environment | -20 - 60 Degrees, 10%--90% Humidity |
| Language | Multilanguage |
| Dimension & Weight (Main Product) | |
| Dimension | 119*119*23mm |
| Package Contents | |
| 1 x TV box | |
| 1 x IR remote control | |
| 1 x HDMI cable | |
| 1 x Power adapter (A right AC Adapter will be sent as your shipping country) | |
| 1 x User manual | |
