Highlights
- Pocket size
- Compliant with CE Standard
- Versatile digital multimeter
- Low power consumption
- DC/AC voltage/current measurement
- Resistance measurement
- Frequency and capacitance measurement
- Audible continuity and Diode test
- Data hold application
- Easy to carry and use
Specification
| General | |
|---|---|
| Model | AIMO M320 |
| Quantity | 1 Piece |
| Specification | |
|
Maximum Display |
3999 |
| DC Voltage | 400mV/4V/40V/400V/600V ±0.8%±3 |
|
AC Voltage |
4V/40V/400V±0.8%±4, 600V ±1.2%±3 |
|
DCA |
40mA/400mA±2.0%±3(Fuse :F500mA/250V) |
|
ACA |
40mA/400mA±3.0%±4(Fuse :F500mA/250V) |
|
Resistance |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ±1.0%±3, 40MΩ±2.0%±3 |
|
Frequency |
10Hz/100Hz/1KHz/10KHz/100KHz±1.5%±3 |
| Cpacitance | 4nF±5%±10, 40nF±4%±5, 400nF/4μF/40μF/100μF±3%±3 |
| Diode Test | Show the approximate forward voltage drop of the diode |
| Audible Continuity Test | Built in buzzer beeping when resisitance is less than 50Ω |
| Power Supply | 2×1.5V LR44 battery |
| Package Contents | |
| 1* Multimeter | |
| 1* Manual | |
