General |
Projection Technology: DLP(0.2"DMD)
Display Chip : RGB LED OSRAM Q8
Light Life: 10,000 hours
Light Luminance: 150ANSI lumen
Light Type: LED(R,G,B)
Standard Resolution: WVGA 854*480
Projection Area: 40-300 inch
Contrast: 500:1
Projection Ratio: 1.4:1(31 inch@1M)
Distortion: <1.5%
Luminance Uniformity: >80%
Projection Distance: 1m - 8m
Aspect Ratio: 4:3/16:9/16:10
Focus mode: Manual focus
Keystone Correction: Automatic, vertical: ± 40 degrees
Projector Character: Interaction
Projection Mode: Front projection
Offset function: 100%
3D: NO
System Parameters
Screen Mirror: Eshare/Airplay/MiraCast
OS: Android 7.1.2
CPU: RK3328
Basic Frequency: Quad-core Cortex-A53 up to 1.5GHz
GPU: Mali-450MP2 GPU
Buffer Memory: 2G DDR3
Memory: 16GB
WIFI: 2.4G/5G Wifi
Bluetooth: BT 4.0
Basic parameters
Built-in Battery : 7.4V 4000mA/h
Usage time: work for 1.5 to 2 hours
Video Support: 4K VP9 and 4K 10bits 1080P AVI(H.264, DIVX, DIVX, XVID, rm, rmvb, WMV, MOV, MP4(H.264, MPEG, DIVX, XVID), DAT(VCD), VOB(DVD), MPEG, MPG, FLV(H.263,H.264), ASF, TS, TP, 3GP, MPG etc
Audio Support: MP3/WMA/AAC/WAV/OGG/DDP/HD/FLAC/APE
Image Support: Supports variety of image formats browsing (HD JPEG/BMP/GIF/PNG/TIFF)
Extended Storage: Support TF Card and Hard Disk
Remote Control: Support IR and 2.4G wireless remote
Built-in speaker: one 3w speaker
Light machine Consumption: 11W
Whole Power Consumption: 18W
Power Performance: AC100-240V,50/60Hz , DC 12V 3A
Interface
1 x TF Card: Max 32G
1 x HDMI: HDMI Input 1.4
2 x USB: One USB 3.0 One USB 2.0
1 x Earphone: Audio output, 3.5mm joint (can connect with earphone or speaker box)
1 x DC input: DC 12V 3A
|
