Highlights
6.2kW Multi-source Hybrid Power Supply
This 6.2kW hybrid inverter supports simultaneous input from solar panels, grid power, and battery storage. It intelligently coordinates multiple energy sources to maximize solar utilization and improve overall system efficiency, delivering stable continuous power for residential and commercial applications.
Smart Time-of-Use Charging & Discharging
Equipped with intelligent timed charge and discharge functions, the system enables peak shaving and valley filling. Users can charge batteries during off-peak hours and discharge during peak-rate periods, significantly reducing electricity costs. Ultra-low no-load loss ensures high efficiency even in standby mode.
Pure Sine Wave Output for Precise & Stable Power Supply
Advanced pure sine wave technology provides clean and stable output, ensuring compatibility with a wide range of household and precision electronics. High-accuracy voltage regulation helps protect sensitive devices and ensures reliable long-term operation without risk of power fluctuation damage.
Smart Monitoring & Flexible Configuration
Built-in MPPT solar controller enhances solar energy harvesting efficiency. Supports external WiFi module and BMS lithium battery communication for real-time system monitoring. LCD display allows easy parameter adjustments based on different usage scenarios, offering intuitive and flexible control.
Comprehensive Protection & Compact Design
Features battery reverse polarity protection and fuse-based circuit safety to prevent electrical faults and extend system lifespan. The compact, lightweight design simplifies transportation, installation, and system integration across various environments.
Specification
| Brand | DAXTROMN |
| Type | Hybrid Solar Inverter |
| Model | JGH-6.2KW |
| Color | White |
| Rated AC Input | 220VAC (Standard) / 110VAC (Optional) |
| Input Voltage Range | 90-280VAC±3V (Normal); 170-280VAC±3V (UPS) |
| Input Frequency | 50/60Hz±5% |
| Rated Power | 6200W |
| Rated Output Power | 6200W |
| Output Voltage | 220/230/240VAC±5% |
| Output Frequency | 50/60Hz±0.1% |
| Output Waveform | Pure Sine Wave |
| Transfer Time | ≤10ms (UPS Mode); ≤20ms (INV Mode) |
| Peak Power | 12400VA |
| Overload Ability | 11s@105%~150% Load; 2s@150%~200% Load |
| Grid-connected Operation | Yes |
| Grid Output Voltage | 220/230/240VAC |
| Grid Voltage Range | 170-265VAC |
| Grid Frequency Range | 49-51±1Hz / 59-61±1Hz |
| Rated Output Current | 26.9A |
| Power Factor Range | >0.99 |
| Peak Efficiency (DC/AC) | 98% |
| Rated Battery Voltage | 48Vdc |
| Max Charging Voltage | 60V |
| Constant Charging Voltage | 56.4Vdc |
| Float Charging Voltage | 54Vdc |
| PV Charging Mode | MPPT |
| Max PV Input Power | 8500W |
| MPPT Input Voltage Range | 60-500Vdc |
| Optimal Vmp Range | 300-400Vdc |
| Max PV Input Voltage | 500Vdc |
| Max PV Input Current | 18A |
| Max PV Charging Current | 120A |
| Max AC Charging Current | 100A |
| Max Charging Current | 120A |
| LCD Interface | Can display operating mode/load/input/output |
| Communication | RS232 (Baud 2400); Wifi/BMS optional slot |
| Parallel Interface | Not Support Parallel |
| Operating Temp | -10°C to 50°C |
| Humidity | 20%~90% Non-condensing |
| Noise | ≤ 50dB |
| Product Weight | 8.8kg |
| Package Weight | 10kg |
| Product Size (L x W x H) | 44×33×14cm |
| Package Size (L x W x H) | 50×39×20cm |
| Package Contents | 1 x Solar Inverter 1 x User Manual |
