Highlights
1. Widely used in the fields of microelectronics, molds, jewelry, printing, mobile phone repair schools, etc.
2. Especially suitable for observing the surface microstructure of large objects.
3. Using high-quality materials, strong and durable, has a long service life.
4. HD camera with 16 megapixel CMOS sensor 1/2.8 inch, with HDMI USB port.
5. Strict quality control and quality assurance, high safety factor, can be used with peace of mind.
Specification
| General | Brand: HAYEAR Type: Microscope Camera with Screen Model: HY-1090 Color: Black |
| Specification | Sensor: 16 Megapixel SONY IMX sensor Pixel Size: 2.0 x 2.0μm Sensor Size: 1/2.8 inch Video Output Interface: HDMI / USB (HD Interface) Resolution: 1920x1080@60FPS (HDMI) Monitor size: 10.1 inches USB Output: 1920x1080@30FPS (USB) Video Ratio: Support 16:9, 4:3 Mode Picture Resolution: 4608 x 3456 Frame Rate: 30@FPS Color: R/G/B support manual adjustment Cross line: 5 horizontal/vertical lines. The Color & size of the line can be adjusted; cross line with scale Zoom: 7X digital zoom Magnifier Function: Support magnifying on the same screen Sensitivity Level: Middle (can be used with an extra light source) Interface for Lens: Standard C/CS Interface Dynamic Range: 40dB PC Systems: Support Windows XP/7/8/10, with measurement software (gift) Picture Format: JPEG Language: CN, EN, JP, FR, DE, RU, IT, KR, TUR Working Voltage: 12V/1A Spectral Response (Wavelength): 400nm-700nm (Strong) White Balance: Manual/Auto SNR: 45dB Mirror Image: Support Up/Down, Right/Left Black & White Mode: Support Storage: TF Card, Maximum support 256GB Working Temperature: -40 - 70 Celsius |
| Weight & Size | Product Weight: 1.2kg Package Weight: 2kg Package Size(L x W x H): 33x25x8cm |
| Package Contents | 1 x Microscope Camera with Screen 1 x Power Supply 1 x USB Cable 1 x Remote Control 1 x HDMI Cable |
