7.1 CHANNEL HD-AUDIO
HiMedia Q10 Pro supports all HD-Audio formats. Dolby True-HD, Dolby True-HD ATMOS, DTS:X, DTS-HD MA, 5.1/7.1 LPCM, DTS, and Dolby Digital AC3 can all be downmixed and bitstreamed (passthrough) using either the built in HiMedia video player app or any version of Kodi with HiMedia wrapper.
2016 HISILICON CHIPSET
New Huawei HiSilicon Hi3798C V200 chipset with quad-core 64bit Cortex A53 CPU and quad-core Mail-720 GPU. Overall performance is amongst the best of any Android box. The Mali-720 GPU is approx 5x more powerful per core than Mali-450 commonly found in other products.
DUAL-BAND WI-FI + GIGABIT LAN
The ultimate in streaming performance. Dual-band Wi-fi (2.4Ghz/5Ghz 802.11AC) with large high-gain antenna gives the best possible reception and transfer rates. Gigabit LAN delivers ultra fast wired networking. Supports remote wakeup and standby via ethernet.
INTERNAL 3.5" HDD BAY
HiMedia Q10 Pro supports an internal 3.5" hard drive up to 8TB. Perfect if you have a large collection of video that you'd prefer to access locally.
23.976 / 29.976 AUTO FRAME RATE SWITCHING
Smooth playback of all video formats. This is an area where HiMedia / HiSilicon have listened to feedback from users and have worked to provide comprehensive support from launch.
2GB RAM + 16GB STORAGE
2GB fast DDR3 RAM allows unhindered performance and 16GB eMMC 5.0 internal eMMC internal storage.
|Model||Himedia Q10 Pro|
|Operating System||Android 7.0|
|CPU||HiSilicon HI3798CV200 Quad-core 64-bit high-performance ARM Cortex A53 with NEON.|
|GPU||High-performance multi-core GPU Mali T720 with OPENGL ES3.1|
|Wifi Connectivity||802.11AC 2.4G/5.8G dual band WIFI with 2 external antennas for stable internet receiving.|
|Ethernet||10/100/1000M, standard RJ-45|
|Video Supported||Perfect playback compatible with 250Mbps 4K UHD movie
Support 192K/24bit audio decoding and output
H.265/HEVC 10bit maximum 4K x [email protected] fps
H.264/VC1/MPEG4/MPEG2/VP9/VP8/VP6/AVS video decoding
Support video post-processing advanced setting
|Picture Supported||HD JPEG/BMP/GIF/PNG/TIFF|
|DOLBY TrueHD and DTS||DOLBY TrueHD and DTS HD Bypass through HDMI|
|HDMI Port||HDMI 2.0a output, 4K x [email protected]|
Support KODI,Youtube and Netflix
Support firmware local update and OTA online update
|1 x TV box|
|1 x IR remote|
|1 x HDMI cable|
|1 x Power adapter (A right AC Adapter will be sent as your shipping country)|
|1 x User manual|
Firmware Upgrade by Recovery Mode (user data will be cleared)1.Download a new firmware and place the firmware onto the ROOT directory of a USB drive.
2. Plug the USB drive into an empty USB HOST on the SMART TV BOX.
3.With the SMART TV BOX turned off,use a paper clip or pen point to press and hold the small pinhole restore button on the SMART TV BOX
4.While pressing the restore button,turn on the SMART TV BOX. Continue to hold the restore button for 5 more seconds,then release it.
5.The SMART TV BOX will begin upgrading the firmware from the USB drive.
6. Wait for the SMART TV BOX to complete the upgrade. Please be patient as it may take around 5 minutes to complete.
7. When finished, The SMART TV BOX will auto reboot.
