Highlights
- Jaw Size: Φ26mm/1.0”
- INRUSH function and True RMS
- Work light and display Back light
- Perform measurements of inrush current, AC/DC voltage and current, resistance, frequency, duty cycle, capacitance, continuity and diode test
- Measuring frequency, AC/DC current, inrush current and duty cycle by clamp
- True root mean square value measuring at AC A and AC V range
- Auto zero function at DCA range
- LCD backlight & clamp lighting bulb
- Provided with one excellent cloth bag for conveniently-carrying
- The meter has both manual range and auto range switching
- Data holding, to hold the readings while taking measurement
- Maximum and minimum value measuring and holding
- Automatic indication of functions and unit symbols.
- Auto power off and low battery indication.
- Full overload protection and dual insulation protection.
- Over-molding rubber case, shake-proof, skid-proof and good touch-feeling.
| General specifications: | |||
| Max. V between terminals & earth: | 600V DC or AC rms | ||
| Operating temperature: | 0 to 40 Celsius Degree (32 Fahrenheit to 104 Fahrenheit) | ||
| Storage temperature: | -10 to 50 Celsius Degree (10 Fahrenheit to 122 Fahrenheit) | ||
| Operating altitude: | Max. 2000 meters (7000 ft.) | ||
| Max. diameter for conductor: | Diameter 26mm | ||
| Max. value displayed: | 6599 digits | ||
| Auto polarity indication: | "-" for negative polarity | ||
| Over-range indication: | "0L" or "-0L" | ||
| Sampling time: | Approx. 0.4 second per sample | ||
| Auto power off time: | 30 minute | ||
| Power supply: | 3 * 1.5V AAA battery (not included) | ||
| Multimeter size: | 20.8 * 7.8 * 3.5cm / 8.2 * 3.1 * 1.4in | ||
| Multimeter weight: | 240g / 8.47oz | ||
| Package size: | 23 * 10.3 * 5.8cm / 9.1 * 4.1 * 2.3in | ||
| Package weight: | 483g / 17.1oz | ||
| Measurement specifications (accuracy): | |||
| AC Current | 66A/600A | ±3.0% | |
| Inrush Current | 66A/600A | <60A take it only as reference; ±10.0% | |
| DC Current | 66A/600A | ±3.0% | |
| DC Voltage | 660mV/6.6V/66V | ±0.8% | |
| 600V | ±1.0% | ||
| AC Voltage | 660mV/600V | ±1.5% | |
| 6.6V/66V | ±1.2% | ||
| Frequency | By A range (from current clamp) | 660Hz/1kHz | ±1.5% |
| >1kHz | Take it only as reference | ||
| By V range | 660Hz/6.6kHz/10kHz | ±1.5% | |
| >10kHz | Take it only as reference | ||
| Resistance | 660Ω/6.6kΩ/66kΩ/660kΩ/6.6MΩ | ±1.2% | |
| 66MΩ | ±2.0% | ||
| Capacitance | 6.6uF/66uF/660uF/6.6mF/66mF | <2uF ±4.0%; ±4.0% | |
What's in the box?
- 1 * Digital Multimeter
- 2 * Test Leads
- 1 * Instruction Manual
