Highlights
- Integrated SX1212 chipset
- Packet handling feature with data whitening and automatic CRC generation
- Programmable RF output power: up to +12.5 dBm in 8 steps
- RSSI (Received Signal Strength Indicator)
- Incoming sync word recognition
- Standard 2.54mm pin pitch
- Built-in Bit-Synchronizer for incoming data and clock synchronization and recovery
- Comes with 10cm antenna
Specification
| General | |
|---|---|
| Type | Transceiver Module |
| Communication Range | 300~500 meters |
| Frequency | 390~470MHz |
| Configuration Modification | 3 Million cycles |
|
Max. Sensitivity |
-110dBm |
| Max. Data Packet | 152 byte |
| Transmission | Transmit power: -8.5~12.5dBm Transmission rate: 1K, 2K, 5K, 10K, 25K, 40Kbps Serial transmission rate: 1200/2400/4800/9600/19200/38400/57600bps |
| Operation | Working voltage: 2.1~3.6V Working temperature: -40~85 Degrees Working humidity: 10~90% |
| Current | Low Rx power consumption: 3mA Low Tx power consumption: 25 mA @ +10 dBm Tx current: 34mA Continuous Rx current: 3mA Sleep current: 1.5uA |
| Package Contents | |
| 1 x module | |
