Highlights
Powerful Cutting & Precise Engraving
The K40 Max delivers high-efficiency cutting in 40W mode, easily handling 20mm paulownia wood and 19mm basswood, while the 20W engraving mode with a 0.08 × 0.1mm compressed laser spot ensures fine details, complex patterns, and small text are reproduced with exceptional precision.
Intelligent Autofocus & Accurate Positioning
Equipped with a full electric Z-axis and a red cross laser, the K40 Max allows one-click autofocus, eliminating manual adjustments and ensuring precise alignment for every cut and engraving.
Advanced Sinking Cutting Technology
With Auto Sinking Cutting and long focal depth, the machine prevents secondary polishing, significantly boosts production efficiency, and delivers cleaner results on each workpiece.
Durable Industrial-Grade Motion System
Dual linear guide rails provide silent operation, high precision, and long-term durability, making the K40 Max ideal for heavy-load processing and continuous professional use.
Versatile Compatibility & Flexible Connectivity
The machine supports optional rollers, rotary attachments, and auxiliary platforms for cylindrical or irregular-shaped workpieces, and is compatible with Windows, macOS, Android, and iOS via USB, Wi-Fi, or TF card.
Comprehensive Safety & Certifications
For secure operation, the K40 Max includes a child lock, flame detection, and tilt shutdown, while holding CE, FCC, RoHS, and FDA certifications, ensuring safe, reliable, and professional-grade performance.
Specification
| Brand | iKier |
| Type | Laser Engraver |
| Model | K40 MAX |
| Engraving Area | 850mm × 800mm |
| Total Power Consumption | 220W |
| Laser Power | 40–48W (cutting) / 20–24W (engraving) |
| Laser Wavelength | 455 ± 5nm |
| Spot Size | 0.08 × 0.1 mm (24W); 0.1 × 0.15 mm (48W) |
| Engraving Precision | 0.01mm |
| Power Supply | 100–240V AC → 12V 7.5A |
| Max Moving Speed | 600mm/s |
| Focusing Method | Auto Focus or Manual Focus, with Red Light Positioning |
| Motorized Z-Axis | Auto Sinking During Cutting |
| Supported OS | Windows, macOS, Android, iOS |
| Control Software | LightBurn, LaserGRBL |
| Supported File Types | png, jpeg, jpg, webp, bmp, gif, dxf, svg |
| Data Transfer | USB, Wi-Fi |
| Mainboard | 32-bit control board with Wi-Fi control port |
| Screen Control | 4.3-inch display |
| Limit Switches | 5 (2 for X-axis, 2 for Y-axis, 1 for Z-axis) |
| Certifications | CE, FCC, RoHS, FDA |
| Flow Rate | 0–60 L/min, stepless adjustable |
| Engraving Materials | Wood, Bamboo, Cardboard, Plastic, Leather, PCB Boards, Oxidized Aluminum, Non-reflective Plated & Painted Metals, 304 Mirror Stainless Steel, Glass, Ceramic, Slate |
| Cutting Materials | Cardboard, Non-woven Fabric, Wood, Non-transparent Acrylic, Some Thin Plastic Sheets |
| Product Weight | 14kg |
| Package Weight | 15kg |
| Product Size | 1125mm × 1090mm |
| Package Size | 820mm × 730mm × 270mm |
| Package Contents | 1 x X rail 1 x Y-left assembly 1 x Y-right assembly 1 x Top support rail 1 x Bottom support rail 2 x Shafts 1 x Laser module 1 x Control screen 1 x Power adapter (K40W MAX) 1 x USB drive 1 x Focusing block 1 x Screws kit 1 x Brush 1 x USB key 1 x Air assist 1 x Goggles 1 x H2 Hex wrench 1 x H2.5 Hex wrench 1 x H3 Hex wrench 1 x HDMI cable 1 x One-to-two computer cable 1 x Power cord 1 x Dust-free cloth 1 x Air pump connecting wire 1 x User Manual |
