Highlights
New Upgrade -Models
450*900mm large cutting area; Equipped with X/Y axis with belt tension to make belt adjustment more convenient. The design of the shifting chains will facilitate the cable management and the appearance will be more accurate. Y-axis -motor adopts an independent design to ensure the stability and synchronization of the y-axis to improve the carving accuracy. Laser class: 4. Laser head:20000mW.
Ultra-Fine Compression Upgrade Fixed Focus
96W machine power, advanced LD+FAC+C lens technology provides cutting accuracy up to 0.01mm, cuts cleaner, thinner, smoother and deeper. The engraving accuracy of 0.01mm enables the machine to create amazing details and extraordinary artwork.
Multiple Safety Protection Devices
1. Equipped with fa lame detection alarm system, it can alarm and stop sculping. 2. After running, the machine measures trigger protection within 10 seconds, ie, laser stop-off light, and effectively prevents burning objects. 3. When the machine tilted, turned over, or dropped more than 15 degrees, the laser head will automatically stop. This increases the safety of using lasers; In addition, the safety cover of laser carving can filter 97% of ultraviolet rays to perfectly protect your eyes
Easy to Operate
Equipped with an emergency button, suitable for one-button on/off; Equipped with an automatic laser lift module, which can adjust laser distance more conveniently; Laser touch auto-focus function, which is more convenient to operate; Support for a variety of operation methods: APP operation, offline operation, online operation
Wide Application
20W high-power laser module, which can engrave/cut a variety of materials. Twotrees TS2-20 Max laser engraver can engrave almost any object, including stainless steel, wood, acrylic, glass (blackened glass surface), ceramic, stone, food, bamboo, plastic, leather, cardboard and round objects (additional rollers required). Add creativity to your designs.
Specification
| General | Brand: TWO TREES Type: Laser Engraver Model: TS2-20 Max Color: Black & Red |
| Specification | Programming software: LaserGRBL(Windows), Lightburn(Common), etc. X/y-axis positioning accuracy: 0.1mm Machine material: Sheet Metal + Aluminium Profile Engraving accuracy: 0.1mm Working range: 450mm x 900mm(17.7in*35.4in) Maximum engraving speed: 6000mm/min Maximum acceleration: 1000mm/s² Supported systems: macOS/Windows Software languages: Chinese/English/Italian/French/German TF memory card/USB port: Supported |
| Weight & Size | Product Weight: 7.2kg Package Weight: 10.4kg Product Size(L x W x H): 123x73.5x19cm Package Size(L x W x H): 125x32x22cm |
| Package Contents | 1 x Front Frame 1 x Y-axis Left Frame 1 x Y-axis Right Frame 1 x Back Frame 1 x X-axis Stepper Motor 1 x X-axis Crossbeam 2 x Bellows Fixed Seat 1 x Tool Package 6 x Cup Head Screw M5*25 2 x Cup head Screw M5*40 5 x Screw Bolt M4*16 4 x Cup Head Screw M3*6 2 x T-nut 2 x Screw Bolt M4*10 4 x M3*14 Countersunk Screw 4 x M3*12 Countersunk Screw 2 x Screw Bolt M3*4 12 x Screw Bolt M3*6 1 x Step Screw 1 x Screw Bolt M5*20 1 x Slide Fixing Seat 1 x Data Cable 1 x Power Cable 1 x Slider 1 x Drag Chains 1 x 20W Laser Head 1 x 24V-4A Power Adapter |
